CSH2200N - 200Amp Circuit Breaker

CSH2200N - 200Amp Circuit Breaker

The Eaton CSH2200N is a 200-amp, two-pole main circuit breaker designed for use in compatible Type ECB Unit Enclosures. It serves as the main disconnect for the electrical system, providing overcurrent protection while allowing power to be safely shut off for maintenance or service work.

This breaker is commonly used in residential, multi-family, and light commercial applications where a 200A service is required. With a 120/240V rating and a 35 kAIC interrupting capacity, it is designed to handle the electrical demands of larger service entrance and distribution systems.

For electricians and maintenance professionals, proper fit matters just as much as electrical ratings. The CSH2200N is intended for use with specific Eaton enclosure configurations, including compatible Type ECB unit enclosures, helping maintain the original equipment setup. Whether you're replacing an existing main breaker or installing new service equipment, the Eaton CSH2200N provides the ampacity, interrupting rating, and compatibility needed for a straightforward installation.

Key Features and Benefits

• 200-amp main circuit breaker for service entrance and distribution applications
• Two-pole configuration for 120/240V electrical systems
• 35 kAIC interrupting rating for fault-current protection
• Designed for use with compatible Eaton Type ECB Unit Enclosures
• Accepts #2 AWG to 300 kcmil copper and aluminum conductors
• Functions as the primary disconnect and overcurrent protection device
• Suitable for residential, multi-family, and light commercial installations
• UL Listed for recognized safety compliance
• Backed by Eaton's limited lifetime residential warranty and one-year commercial warranty


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: CSH2200N

• Product Type: Main Circuit Breaker

• Frame Type: CSH

• Main Circuit Breaker Type: CH

• Amperage Rating: 200 A

• Voltage Rating: 120/240 V AC

• Number of Poles: 2

• Interrupt Rating: 35 kAIC

• Wire Size Range: #2 AWG – 300 kcmil Cu/Al

• Used With: CH32NLPN225J, CH42NLPN225K, Type ECB Unit Enclosures

• Dimensions:
  • Depth: 6.5 in.
  • Height: 5 in.
  • Width: 5 in.
• Weight: 2.8 lb

• UPC: 782113099767


Material Compliance and Certifications

The Eaton CSH2200N is UL Listed and designed for installation in approved Eaton electrical equipment. It meets recognized safety standards for main circuit breaker applications and is supported by Eaton's limited lifetime residential warranty and one-year commercial warranty.

Where It Works Best

• Residential service equipment
• Apartment and condominium electrical systems
• Multi-family housing projects
• Light commercial buildings
• Service entrance upgrades
• Main breaker replacement projects
• New construction electrical installations
• Compatible Eaton Type ECB Unit Enclosures
