CR463L40AJA - GE Contactor

CR463L40AJA - GE Contactor

The ABB CR463L40AJA 463L Lighting Contactor is an electrically held lighting contactor designed for dependable control of lighting circuits in commercial, institutional, and industrial environments. Featuring a 4-pole configuration with four normally open (4NO) contacts and a 120V 60 Hz / 110V 50 Hz control coil, this contactor provides a practical solution for managing lighting loads from a centralized control system. Whether you're using it in office buildings, schools, warehouses, manufacturing facilities, or large retail spaces, the CR463L40AJA helps simplify lighting control while supporting efficient operation of connected lighting equipment.

Built as part of ABB's proven CR463 lighting contactor family, this unit is well-suited for new installations, system expansions, and replacement applications where reliable switching of lighting loads is required. Its compact design allows for installation in control panels and lighting control assemblies where space may be limited, while the electrically held mechanism maintains contact position as long as control power is present. For facility managers, electrical contractors, and maintenance teams, the CR463L40AJA offers a straightforward way to maintain consistent lighting control performance throughout a building's electrical system.

Key Features and Benefits

• Electrically held lighting contactor for commercial and industrial lighting control
• Four normally open (4NO) power poles
• 120V 60 Hz / 110V 50 Hz control coil
• Designed for centralized lighting control applications
• Rated for 30A full-load AC resistance (heating) loads
• Suitable for new installations, maintenance, and retrofit projects
• Compact footprint for panel and enclosure installations
• Supports dependable switching of lighting circuits
• Compatible with a wide range of building lighting control systems
• Manufactured by ABB for long-term service in demanding environments

Technical Specifications

• Catalog Number: CR463L40AJA

• Manufacturer: ABB

• Product Series: CR463L Lighting Contactor

• Product Type: Electrically Held Lighting Contactor

• Configuration: 4NO (Four Normally Open Contacts)

• Coil Voltage: 120V AC 60 Hz / 110V AC 50 Hz

• Product ID: 7GSP024406R0006

• Full Load Amps (AC Resistance Heating): 30A

• Dimensions:
  • Width: 4.18 in
  • Depth: 3.86 in
  • Height: 7.39 in
• Weight: 3.59 lb

• Application: Lighting control systems

• ETIM Classification: EC000533 – Lighting Control System Component

• UNSPSC: 39121529


Material Compliance and Certifications

The CR463L40AJA is supported by UL Certificate E1811 and is backed by ABB's compliance documentation for key environmental and regulatory requirements. Available declarations include REACH compliance, TSCA compliance, and Conflict Minerals Reporting Template (CMRT) documentation. The product is classified as Business-to-Business (B2B) equipment under WEEE requirements and falls within WEEE Category 5 – Small Equipment.

Where It Works Best

• Commercial office buildings
• Schools and educational facilities
• Warehouses and distribution centers
• Manufacturing plants
• Retail stores and shopping centers
• Healthcare facilities
• Municipal and government buildings
• Lighting control panels
• Building automation systems
• Lighting retrofit and replacement projects

When dependable lighting control is essential, the ABB CR463L40AJA provides a proven solution for switching and controlling lighting loads in a wide variety of commercial and industrial applications. Its electrically held design, four-pole configuration, and compatibility with centralized lighting systems make it a practical choice for contractors, facility operators, and maintenance professionals looking to keep lighting systems operating efficiently.
