CQD390 - 90Amp Circuit Breaker

CQD390 - 90Amp Circuit Breaker

If you’re working inside an existing Siemens CQD panelboard system, the CQD390 is the kind of breaker that helps everything stay stable, consistent, and easy to maintain. It’s a 90 amp, 3-pole molded case circuit breaker designed for 480/277V applications, commonly used in commercial and industrial electrical distribution setups where keeping compatibility with existing equipment is the priority.

In everyday operation, this breaker is typically used for three-phase power distribution, lighting circuits, and general branch circuit protection. The 90A rating supports higher electrical loads found in commercial facilities, while the 14kA interrupt rating provides standard protection against fault conditions in this class of system. It’s not about reinventing the setup—it’s about keeping established Siemens CQD systems running the way they were designed to.

The DIN rail mounting design keeps installation clean and efficient, allowing the breaker to snap into compatible panels while maintaining an organized layout that makes future servicing and inspections easier.

Key Features and Benefits

• Siemens CQD series breaker designed for existing panelboard systems
• 90A, 3-pole configuration for 480/277V applications
• 14kA interrupt rating for standard commercial circuit protection
• DIN rail mounting for quick, clean installation
• Commonly used in three-phase distribution and lighting circuits
• Ideal for like-for-like replacement in CQD systems
• Helps maintain consistency in established electrical infrastructure
• Supports organized, service-friendly panel layouts
• Designed for maintenance and system continuity work
• Compact design for efficient panel space usage

Technical Specifications

• Model: CQD390

• Series: Siemens CQD

• Amperage: 90A

• Poles: 3

• Voltage Rating: 480/277V AC

• Interrupt Rating: 14kAIC

• Mounting Type: DIN rail

• Application: Commercial and industrial branch circuit protection


Material Compliance and Certifications

Manufactured in accordance with applicable UL and IEC standards for molded case circuit breakers used in commercial electrical systems. Installation should always be performed by a qualified electrician in compliance with local electrical codes and safety requirements.

Where It Works Best

• Existing Siemens CQD panelboard systems
• Commercial lighting and power distribution circuits
• 480V three-phase electrical systems
• 277V lighting control applications
• Maintenance and breaker replacement projects
• Industrial and commercial electrical panels
• DIN rail enclosure installations
• Facilities maintaining legacy Siemens infrastructure
