CLD3600 - 600Amp Circuit Breaker

CLD3600 - 600Amp Circuit Breaker

The CLD3600 Eaton LD frame circuit breaker is a 600 Amp, 3-pole molded case circuit breaker used in commercial and industrial power distribution systems where larger electrical loads need dependable circuit protection. In everyday terms, this is the kind of breaker you’ll find in main service sections and feeder applications inside switchboards or panelboards that are already built around Eaton LD equipment.

In the field, the CLD3600 is usually part of existing infrastructure rather than a redesign. It’s commonly used when maintaining or replacing breakers in systems already in service, where preserving the original equipment layout matters. Because it belongs to the Eaton LD family, it fits into compatible assemblies without requiring changes to the panel design, which makes it practical for service work and system upkeep.

With interrupting ratings of 65kA at 240VAC, 35kA at 480VAC, and 25kA at 600VAC, the CLD3600 is built for systems where available fault current has to be properly accounted for. The 3-pole design ensures all phases open together, which is standard for three-phase distribution and helps maintain consistent system behavior during fault conditions.

Key Features and Benefits

• 600 Amp, 3-pole molded case circuit breaker for Eaton LD frame systems
• Designed for 240V, 480V, and 600V power distribution systems
• 100% rated for full-load operation in compliant installations
• Interchangeable trip unit for coordination flexibility
• High interrupting ratings: 65kA (240V), 35kA (480V), 25kA (600V)
• 3-pole design for simultaneous phase protection
• Includes load terminals for compatible assemblies
• Used in feeder and main service applications
• 40°C rated for defined operating environments
• Built for use in properly engineered electrical systems

Technical Specifications

• Catalog Number: CLD3600
• Product Type: Molded Case Circuit Breaker
• Frame Type: LD
• Amperage Rating: 600 Amps
• Poles: 3
• Voltage Rating: 240V / 480V / 600V AC
• Interrupting Rating: 65kA @ 240V; 35kA @ 480V; 25kA @ 600V
• Trip Unit: Interchangeable
• Rating: 100% rated
• Temperature Rating: 40°C
• Includes: Load terminals
• Dimensions: 8.25"W x 10.75"H x 4.06"D
• Ship Weight: 24.00 lbs

Material Compliance and Certifications

The CLD3600 Eaton LD molded case circuit breaker is designed for use in accordance with applicable UL standards for industrial electrical distribution equipment. It is intended for installation in Eaton-compatible LD frame assemblies and should be installed by qualified electrical personnel following all applicable electrical codes and manufacturer guidelines.

Where It Works Best

• Eaton LD frame switchboards and panelboards
• Main service and feeder circuit protection
• Commercial and industrial electrical distribution systems
• 240V, 480V, and 600V three-phase applications
• Facilities with higher-capacity electrical loads
• Maintenance and replacement in existing LD systems
• Engineered power distribution setups requiring trip coordination
