CHH3200 - 200Amp Circuit Breaker

CHH3200 - 200Amp Circuit Breaker

When you’re replacing a breaker in an existing CHH system, it’s usually not about changing anything—it’s about matching what’s already there so the panel keeps running the way it was originally set up. The CHH3200 is a 200 Amp, 3-pole molded case circuit breaker used in CHH-series equipment where a direct replacement is needed to keep everything aligned with the original design.

With a 100kA interrupting rating at 240VAC, the CHH3200 is used in systems where fault current levels have already been defined by the original electrical design. The replacement needs to match that rating so the system continues operating within its intended limits.

The non-interchangeable trip unit is factory set and not field adjustable. There are no plug-in or replaceable trip components, which keeps the replacement process simple and consistent when working inside existing CHH-series panels.

Like other molded case breakers used in established electrical systems, it’s intended for service in properly maintained equipment and is built to last under normal operating conditions.

Key Features & Benefits

• 200 Amp molded case circuit breaker
• 3-pole configuration for three-phase systems
• CHH-series frame design
• 240VAC rated application
• 100kA interrupting rating at 240VAC
• Non-interchangeable factory-set trip unit
• Direct replacement for compatible CHH breakers
• Maintains existing panel layout and footprint
• Common in commercial and industrial electrical systems
• Used for maintenance and like-for-like replacement work

Technical Specifications

• Part Number: CHH3200
• Type: CHH
• Product Category: Molded Case Circuit Breaker
• Amperage Rating: 200 Amps
• Poles: 3
• Voltage Rating: 240VAC
• Interrupting Rating: 100kAIC @ 240VAC
• Trip Unit: Non-Interchangeable
• Dimensions: 4.13"W x 7.50"H x 3.06"D
• Width: 4.13 in.
• Height: 7.50 in.
• Depth: 3.06 in.
• Approximate Shipping Weight: 8.5 lbs

Material Compliance and Certifications

The CHH3200 is intended for use in equipment designed to accept compatible CHH-series molded case circuit breakers. Installation should be performed by qualified electrical personnel and in accordance with applicable electrical codes and safety standards. Always confirm compatibility with the existing system before installation, including voltage rating, interrupting capacity, and physical fit.

Where It Works Best

• Existing CHH-series electrical systems
• Commercial and industrial facilities
• Three-phase power distribution setups
• Feeder and branch circuits
• Maintenance and repair work
• Like-for-like breaker replacement applications
• Systems requiring a 200 Amp, 3-pole breaker
• Installations where keeping the original configuration is important
