CHH2100 - 100Amp Circuit Breaker

CHH2100 - 100Amp Circuit Breaker

The CHH2100 is a 100 Amp two-pole molded case circuit breaker designed for your applications that require dependable overcurrent protection in systems operating at up to 240VAC. Commonly found in commercial, industrial, and heavy-duty electrical distribution equipment, this breaker is used where higher interrupting capacity is needed to safely handle available fault current while maintaining the original system configuration.

As part of Eaton's CHH series, the CHH2100 is often installed as a direct replacement for an existing breaker with matching ratings and physical dimensions. Maintaining the same breaker type helps preserve the panel or switchboard's intended design, minimizing the need for modifications during maintenance or repair work.

This model features a non-interchangeable trip unit, meaning the trip characteristics are factory-matched to the breaker assembly. That design helps you ensure the breaker operates according to its intended specifications throughout its service life. Built with a molded case construction, the CHH2100 is designed to withstand the demands of everyday electrical distribution systems while providing protection against overloads and short circuits.

With a 100kA interrupting rating at 240VAC, the CHH2100 is suitable for installations where higher fault-current levels are present. It is frequently used in electrical distribution systems, feeder circuits, machinery installations, and other applications requiring a two-pole breaker with a 100 Amp rating.

Key Features and Benefits

• 100 Amp two-pole molded case circuit breaker
• Part of the Eaton CHH breaker family
• Designed for overload and short-circuit protection
• Non-interchangeable factory-installed trip unit
• Rated for systems up to 240VAC
• High 100kA interrupting capacity
• Suitable for commercial and industrial electrical distribution systems
• Helps maintain original equipment configuration during replacement
• Molded case construction built for long-term service
• Direct replacement option for compatible CHH installations

Technical Specifications

• Catalog Number: CHH2100

• Manufacturer: Eaton

• Product Type: Molded Case Circuit Breaker

• Series: CHH

• Amperage Rating: 100 Amps

• Poles: 2

• Voltage Rating: 240VAC

• Interrupting Rating: 100kAIC @ 240VAC

• Trip Unit: Non-Interchangeable

• Dimensions:
  • Width: 2.75 in
  • Height: 7.50 in
  • Depth: 3.06 in
• Approximate Shipping Weight: 7.00 lb


Material Compliance and Certifications

• The CHH2100 is manufactured for use in compatible Eaton electrical distribution equipment and is intended for installation by qualified electrical personnel.
• All installations should comply with applicable national, state, and local electrical codes.
• Users should verify compatibility with existing equipment and system requirements prior to installation.

Where It Works Best

• Commercial electrical distribution systems
• Industrial power distribution equipment
• Feeder circuit protection
• Motor and machinery power circuits
• Switchboards and distribution panels
• Maintenance and repair projects requiring CHH-series replacements
• Applications with elevated available fault current levels
• Installations requiring 100 Amp, 2-pole protection
• Facilities maintaining existing Eaton CHH equipment
• Electrical systems where preserving original form, fit, and function is important
