CHFCAF115 - 15Amp Circuit Breaker

CHFCAF115 - 15Amp Circuit Breaker

The Eaton CHFCAF115 is a 15 Amp single-pole Combination AFCI circuit breaker designed for use in compatible Eaton Type CH loadcenters. It's commonly used on residential branch circuits where arc fault protection is required and is often installed when replacing an existing CH-series AFCI breaker or maintaining an Eaton CH panel.

Unlike a standard circuit breaker, the CHFCAF115 is designed to detect certain types of arc faults that can occur from damaged wiring, loose electrical connections, or deteriorated conductors. When an arc fault is detected, the breaker interrupts power to the circuit. It also provides traditional thermal-magnetic protection against overloads and short circuits.

This breaker features a plug-on design with a pigtail connection and is rated for 15 amps with a 10 kAIC interrupt rating. It's commonly used on bedroom circuits, living areas, hallways, home offices, receptacle circuits, and lighting circuits where AFCI protection may be required by code.

Whether you're replacing a failed breaker, matching an existing panel configuration, or performing routine electrical maintenance, the CHFCAF115 provides the proper fit for approved Eaton CH loadcenters and is built to last.

Key Features and Benefits

• Genuine Eaton Type CH combination AFCI circuit breaker
• 15 Amp current rating for branch circuit protection
• Single-pole configuration
• Combination Arc Fault Circuit Interrupter (AFCI) technology
• Detects potentially dangerous arc fault conditions
• Thermal-magnetic protection against overloads and short circuits
• Plug-on design for use in compatible Type CH loadcenters
• Pigtail connection for AFCI functionality
• 120/240V voltage rating
• 10 kAIC interrupting capacity
• Helps improve residential electrical safety
• Suitable for applications requiring AFCI protection
• Compact design conserves panel space
• Limited lifetime warranty

Technical Specifications

• Manufacturer: Eaton

• Catalog Number: CHFCAF115

• Product Type: AFCI Circuit Breaker

• Series: CH

• Breaker Type: Plug-On Branch Feeder Arc Fault Combination Circuit Breaker

• Amperage Rating: 15 Amps

• Number of Poles: 1 Pole

• Voltage Rating: 120/240V

• Interrupt Rating: 10 kAIC

• Connection Type: Pigtail

• Main Circuit Breaker Family: CH

• Compatible Load Centers: Type CH Loadcenters

• Height: 3 in.

• Width: 1 in.

• Depth: 3.5 in.

• Weight: 0.5 lb.


Material Compliance and Certifications

• UL Listed
• HACR Rated
• Manufactured to meet applicable industry standards for circuit protection devices
• Designed for installation in approved Eaton Type CH electrical distribution equipment
• Suitable for residential electrical systems requiring AFCI protection
• Built to support code-compliant branch circuit protection when installed according to applicable electrical codes

Where It Works Best

The Eaton CHFCAF115 is commonly used in:

• Residential Type CH loadcenters
• New residential construction projects
• Electrical panel upgrades and renovations
• Bedroom branch circuits
• Living rooms and family rooms
• Dining rooms and hallways
• Home office circuits
• General-purpose residential receptacle circuits
• Residential lighting circuits
• AFCI-protected branch circuits required by local electrical codes
• Replacement of existing compatible Eaton CH AFCI breakers

The CHFCAF115 is commonly used in Eaton Type CH loadcenters where 15 Amp AFCI protection is specified. It's a direct replacement option for compatible residential electrical systems and is frequently used on branch circuits that require arc fault protection.
