CHB360 - 60Amp Circuit Breaker

CHB360 - 60Amp Circuit Breaker

The Eaton CHB360 is a 60 Amp, three-pole circuit breaker used in Eaton CH Loadcenters, and it’s typically installed when you need a direct replacement that matches an existing breaker already in the panel.

In day-to-day use, this breaker is usually found in residential and light commercial systems handling medium three-pole 240V loads. Most of the time, it’s not about changing anything—it’s about replacing like-for-like so the system keeps operating the way it was originally set up.

Installation is simple in compatible Eaton CH Loadcenters. The plug-in design lets the breaker seat directly into the panel without modification, which keeps the work straightforward when servicing an existing system. Inside, the CHB360 uses a thermal magnetic trip system, which responds to both overload and short-circuit conditions. It’s rated at 10 kAIC, which matches typical fault levels found in standard CH residential and light commercial installations.

At its core, the CHB360 is a direct replacement breaker for Eaton CH Loadcenters. It’s meant to keep existing systems consistent and properly matched, without changing the panel layout or introducing compatibility issues.

Key Features and Benefits

• 60 Amp, 3-pole breaker for Eaton CH Loadcenters
• Designed for 240V three-pole circuits
• Plug-in installation for compatible CH panels
• Thermal magnetic protection for overloads and short circuits
• 10 kAIC interrupt rating for standard fault conditions
• Compatible with #8–2 AWG conductors
• Three-pole switching for simultaneous disconnect
• Keeps original CH panel layout unchanged
• Common in residential and light commercial systems
• Direct replacement for existing CH breakers

Technical Specifications

• Catalog Number: CHB360

• Product Type: Thermal magnetic circuit breaker

• Type: CHB

• Amperage Rating: 60 Amps

• Voltage Rating: 240V AC

• Number of Poles: 3

• Interrupt Rating: 10 kAIC

• Wire Size: #8–2 AWG

• Mounting Style: Plug-in (Eaton CH Loadcenters)

• Dimensions: 3.7 in D x 3.3 in H x 1.5 in W

• Weight: 0.6 lb

Material Compliance and Certifications

• The Eaton CHB360 is UL 489 listed, meeting standard safety requirements for branch circuit protection. It is intended for installation in Eaton CH Loadcenters and should be installed by a qualified electrician following applicable electrical codes and safety requirements.

Where It Works Best

• Eaton CH Loadcenters
• Residential electrical panels
• Light commercial electrical systems
• Three-pole 240V circuits
• Replacement of existing CH 60A breakers
• Maintenance work in installed CH systems
• Circuits requiring all poles to trip together
• Situations where matching existing panel layout matters
