CH3090 - 90Amp Circuit Breaker

CH3090 - 90Amp Circuit Breaker

The Challenger CH3090 Circuit Breaker is an essential component designed for reliable electrical protection in residential, commercial, and industrial settings. This molded case circuit breaker features a fixed thermal and magnetic trip unit, ensuring consistent and dependable performance under varying electrical loads. With a three-pole configuration, the CH3090 provides robust overcurrent protection, safeguarding your electrical systems from damage caused by overloads and short circuits. Rated at 90 Amps, it operates efficiently at both 480Y/277 VAC and 125/250 VDC, making it versatile for different voltage requirements.

Key Features and Benefits:

• Versatile Voltage Ratings: Operates efficiently at 480Y/277 VAC and 125/250 VDC, providing flexibility for various applications.
• High Interrupting Capacity: With 65 kAIC at 240 VAC and 14 kAIC at 480Y/277 VAC, it ensures superior protection against overcurrent and short circuits.
• Robust Overcurrent Protection: The three-pole configuration and fixed thermal and magnetic trip unit deliver reliable performance under diverse electrical loads.

Technical Specifications:

• Rated Current: 90 Amps
• Poles: 3
• Voltage Rating: 480Y/277 VAC, 125/250 VDC
• Frequency Rating: 50/60 Hz
• Interrupting Capacity: 65 kAIC at 240 VAC, 14 kAIC at 480Y/277 VAC
• Trip Type: Fixed thermal, fixed magnetic
• Dimensions: 3.00"W x 4.00"L x 2.63"D
• Weight: 3.75 lb

Material Compliance and Certifications:

• Compliance: The Challenger CH3090 Circuit Breaker adheres to stringent quality and safety standards, ensuring reliable performance and long-term durability.
• Certifications: It is UL Listed, meeting the rigorous requirements set by Underwriters Laboratories for electrical safety. Additionally, it complies with Federal Specifications Classification WC375B, underscoring its adherence to federal safety and performance standards.

Suitability:

• The Challenger CH3090 is ideal for a variety of applications, including residential homes, commercial buildings, and industrial facilities. Its versatile voltage ratings and high interrupting capacity make it suitable for protecting circuits in complex electrical systems. Whether you're upgrading your current electrical infrastructure or installing a new system, the CH3090 offers the reliability and safety needed to keep your electrical systems functioning smoothly. With its robust design and trusted performance, this circuit breaker is an excellent choice for ensuring the protection and longevity of your electrical installations.
