CH3080 - 80Amp Circuit Breaker

CH3080 - 80Amp Circuit Breaker

The Challenger CH3080 circuit breaker is a high-performance molded case circuit breaker engineered for robust and efficient protection in electrical systems. With an 80-amp current rating, this three-pole breaker is versatile, suitable for both AC and DC systems, and operates at 480Y/277 VAC and 125/250 VDC. Its fixed thermal and magnetic trip units ensure consistent circuit protection, minimizing downtime and enhancing safety.

Key Features and Benefits:

• High Performance: Provides reliable protection with an 80-amp rating, ideal for various commercial and industrial applications.
• Versatile Application: Suitable for both AC and DC systems with voltage ratings of 480Y/277 VAC and 125/250 VDC.
• Robust Protection: Fixed thermal and magnetic trip units offer dependable circuit protection, reducing the risk of electrical faults.
• High Interrupting Capacity: Handles fault currents with an interrupt rating of 14 kAIC at 480Y/277 VAC and 65 kAIC at 240 VAC.

Technical Specifications:

• Frame: CH-frame
• Amperage Rating: 80 A
• Voltage Rating: 480Y/277 VAC, 125/250 VDC
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 14 kAIC at 480Y/277 VAC, 65 kAIC at 240 VAC
• Poles: 3
• Dimensions: 3.00"W x 4.00"L x 2.63"D
• Weight: 3.75 lb
• Frequency Rating: 50/60 Hz

Material Compliance and Certifications:

• The Challenger CH3080 circuit breaker is UL listed, meeting stringent industry standards for safety and performance. It complies with Federal Specifications Classification WC375B, ensuring it is suitable for various demanding applications.

Suitability:

• Ideal for commercial and industrial settings, the CH3080 provides reliable protection with its high interrupting capacity, making it an excellent choice for critical power distribution systems. Its robust design and dependable performance make it a preferred option for electrical professionals.
