CH3060 - 60Amp Circuit Breaker

CH3060 - 60Amp Circuit Breaker

Introducing the Challenger CH3060 Circuit Breaker, a premium choice for robust electrical protection in both commercial and industrial settings. Engineered with fixed thermal and magnetic trip units, the CH3060 ensures reliable protection against overloads and short circuits. It operates at 480Y/277 Vac and 125/250 Vdc, making it versatile for various high-demand applications. The breaker boasts impressive interrupting ratings of 14 kAIC at 480Y/277 Vac and 65 kAIC at 240 Vac, providing exceptional fault current management.

Key Features and Benefits:

• High Reliability: The fixed thermal and magnetic trip mechanisms provide consistent, reliable performance.
• Versatility: Suitable for a wide range of applications with dual voltage ratings (480Y/277 Vac and 125/250 Vdc).
• Robust Protection: High interrupting capacity ensures excellent protection against high fault currents.

Technical Specifications:

• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Amperage Rating: 60 A
• Frequency: 50/60 Hz
• Interrupt Rating: 14 kAIC at 480Y/277 Vac, 65 kAIC at 240 Vac
• Trip Type: Fixed thermal, fixed magnetic
• Poles: 3
• Dimensions: 2.63 in (Length), 4 in (Height), 3 in (Width)
• Weight: 3.75 lb

Material Compliance and Certifications:

• Certifications: UL Listed, Federal Specifications Classification WC375B

Suitability:

• The CH3060 Circuit Breaker is ideal for use in commercial and industrial electrical systems requiring reliable protection and high fault current handling. Its robust design and high interrupting capacity make it suitable for critical applications where safety and reliability are paramount.

Elevate your electrical protection with the Eaton CH3060, designed to deliver exceptional performance and peace of mind.
