CH3045 - 45Amp Circuit Breaker

CH3045 - 45Amp Circuit Breaker

Designed for superior performance, this circuit breaker is a robust and versatile solution for a wide range of electrical applications. With a fixed thermal and magnetic trip type, the CH3045 ensures reliable protection against overloads and short circuits. It operates efficiently in both AC and DC environments, with a voltage rating of 480Y/277 Vac and 125/250 Vdc, making it ideal for various commercial and industrial settings.

Key Features and Benefits:

• Reliable Protection: The fixed thermal and magnetic trip mechanism provides dependable protection against electrical faults, ensuring safety and reducing the risk of damage to your electrical systems.
• Versatile Application: Suitable for both AC (50/60 Hz) and DC applications, with a voltage rating of 480Y/277 Vac and 125/250 Vdc, making it a versatile choice for various electrical setups.
• High Interrupting Capacity: With an interrupt rating of 65 kAIC at 240 Vac and 14 kAIC at 480Y/277 Vac, the CH3045 can handle high fault currents, providing enhanced safety and reliability.

Technical Specifications:

• Amperage Rating: 45 A
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Trip Type: Fixed thermal, fixed magnetic
• Frequency: 50/60 Hz
• Interrupting Capacity: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
• Number of Poles: Three-pole
• Dimensions: 2.63 in (depth) x 4 in (height) x 3 in (width)
• Weight: 3.75 lb

Material Compliance and Certifications:

• The CH3045 circuit breaker is UL Listed, confirming its adherence to rigorous safety and performance standards. It complies with Federal Specifications Classification WC375B, ensuring it meets federal quality standards.

Suitability:

• The Challenger CH3045 is ideal for commercial and industrial applications where reliable electrical protection is paramount. Its robust design and high interrupting capacity make it suitable for use in a variety of settings, including manufacturing plants, commercial buildings, and other environments where electrical reliability and safety are critical.
