CH3035 - 35Amp Circuit Breaker

CH3035 - 35Amp Circuit Breaker

Elevate your electrical safety standards with the Challenger CH3035 circuit breaker, a robust and efficient solution designed to protect your electrical infrastructure. Engineered with precision and reliability, this circuit breaker ensures uninterrupted power distribution and safety in both residential and commercial applications.

Key Features and Benefits:

• High Interrupting Capacity: With an interrupting rating of 14 kAIC at 480Y/277 Vac and 65 kAIC at 240 Vac, the CH3035 offers exceptional fault current interruption, providing enhanced protection against electrical faults.
• Fixed Thermal and Magnetic Trip: This breaker features fixed thermal and magnetic trip settings, ensuring precise and consistent operation, making it ideal for a wide range of applications.
• Versatile Voltage Ratings: Suitable for both AC and DC applications, it operates efficiently at 480Y/277 Vac and 125/250 Vdc, offering flexibility for various power systems.
• Three-Pole Configuration: The three-pole design ensures balanced protection across all phases, enhancing system reliability and safety.

Technical Specifications:

• Amperage Rating: 35 A
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 14 kAIC at 480Y/277 Vac, 65 kAIC at 240 Vac
• Trip Type: Fixed Thermal, Fixed Magnetic
• Number of Poles: 3
• Dimensions: Length 2.63 in, Height 4 in, Width 3 in
• Weight: 3.75 lb

Material Compliance and Certifications:

• UL Listed: This circuit breaker meets the rigorous safety and performance standards set by Underwriters Laboratories, ensuring reliable operation and peace of mind.
• Federal Specifications Classification WC375B: Complies with federal specifications, underscoring its quality and suitability for diverse applications.

Suitability:

• The CH3035 is ideal for a variety of settings, including residential, commercial, and industrial environments. Its high interrupting capacity and reliable trip mechanisms make it perfect for protecting electrical systems from overloads and short circuits. Whether you're upgrading an existing panel or installing a new system, the CH3035 provides the protection and performance you need to keep your electrical infrastructure running smoothly.
