CH3030 - 30Amp Circuit Breaker

CH3030 - 30Amp Circuit Breaker

Elevate the safety and efficiency of your electrical installations with the CH3030 Circuit Breaker from Challenger. Designed to offer robust and reliable protection for a variety of electrical systems. Whether you're managing a commercial facility or industrial operation, the CH3030 is engineered to meet rigorous standards, ensuring uninterrupted power flow and safeguarding against electrical faults.

Key Features and Benefits:

• High Interrupting Capacity: With a 65 kAIC at 240 Vac and 14 kAIC at 480Y/277 Vac, the CH3030 is capable of handling high fault currents, providing exceptional protection and minimizing downtime.
• Versatile Application: Rated for 30 Amps with fixed thermal and magnetic trip types, this breaker supports both AC (480Y/277 Vac) and DC (125/250 Vdc) systems, making it suitable for a wide range of applications.
• Durability and Reliability: Built to last, the CH3030 features a molded case design that ensures durability and long-term reliability, even in demanding environments.

Technical Specifications:

• Amperage Rating: 30 A
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
• Frequency: 50/60 Hz
• Number of Poles: Three-pole
• Dimensions: 2.63 in (L) x 4 in (H) x 3 in (W)
• Weight: 3.75 lb

Material Compliance and Certifications:

• Certifications: UL Listed for safety and performance
• Compliance: Meets Federal Specifications Classification WC375B, ensuring it adheres to stringent federal standards.

Suitability:

• The CH3030 Circuit Breaker is ideal for a wide range of applications, including commercial buildings, industrial facilities, and critical infrastructure projects. Its high interrupting capacity and versatile voltage ratings make it suitable for protecting electrical circuits in environments where reliability and safety are paramount. Whether you're upgrading existing systems or installing new ones, the CH3030 provides peace of mind with its robust performance and comprehensive safety features.
