CH3025 - 25Amp Circuit Breaker

CH3025 - 25Amp Circuit Breaker

Introducing the Challenger CH3025 Circuit Breaker, a robust and reliable solution for protecting your electrical systems. Designed for demanding industrial applications, the CH3025 ensures superior performance with its fixed thermal and fixed magnetic trip types. This three-pole circuit breaker, rated at 25 Amps, is engineered to handle 480Y/277 Vac and 125/250 Vdc at 50/60 Hz, providing exceptional versatility and safety for your electrical infrastructure.

Key Features and Benefits:

• Fixed Thermal and Magnetic Trip: The CH3025 features a fixed thermal and magnetic trip, offering consistent and reliable protection against overloads and short circuits.
• High Interrupting Capacity: With an interrupting capacity of 65 kAIC at 240 Vac and 14 kAIC at 480Y/277 Vac, this circuit breaker is built to handle high fault currents, ensuring the safety and integrity of your electrical system.
• Versatile Application: Suitable for both AC and DC applications, the CH3025 supports a wide range of industrial and commercial settings, enhancing its flexibility and usability.

Technical Specifications:

• Amperage Rating: 25 A
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
• Number of Poles: 3
• Dimensions: Length - 2.63 in, Height - 4 in, Width - 3 in
• Weight: 3.75 lb

Material Compliance and Certifications:

• The Challenger CH3025 circuit breaker meets Federal Specifications Classification WC375B and is UL Listed, ensuring compliance with stringent safety and performance standards.

Suitability:

• The CH3025 is ideal for a variety of industrial and commercial applications requiring dependable circuit protection. Its high interrupting capacity and robust design make it suitable for use in critical environments such as manufacturing plants, data centers, and commercial buildings. The fixed thermal and magnetic trip mechanisms ensure consistent performance, safeguarding your electrical systems from potential hazards.
