CH240GF - 40Amp Circuit Breaker

CH240GF - 40 Amp Circuit Breaker

The CH240GF circuit breaker is a 40 amp, 2 pole breaker designed for use in compatible CH series load centers and panelboards. Rated at 120/240VAC with a 10kA interrupting capacity, it provides reliable overcurrent protection for branch circuits serving larger residential or light commercial loads. Built on the CHGF frame, this plug-on style breaker is intended for proper form, fit, and function in existing electrical systems where a matching CH-type breaker is required. With its compact design (approximately 4.63 inches tall) and straightforward plug-on installation, the CH240GF is commonly used when maintaining or servicing panels that require a 2-pole, 40A breaker. It is built with durable internal components designed for long service life under normal operating conditions. Matching the correct amperage, voltage rating, and frame type helps ensure safe and consistent performance within the panel.

Key Features and Benefits

• 40 Amp rating for branch circuits requiring 40A protection
• 2 poles for use on 120/240VAC systems
• 10kA A.I.C. rating at 120/240VAC
• CHGF frame type for compatibility with designated CH series panels
• Plug-on style mounting for proper installation in approved load centers
• Designed for form, fit, and functional replacement applications
• Built to last with durable construction

Technical Specifications

• Part Number: CH240GF

• Amperage: 40A

• Poles: 2

• Voltage Rating: 120/240VAC

• A.I.C. Rating: 10k @ 120/240VAC

• Frame Type: CHGF

• Mounting Style: Plug-On

• Approximate Height: 4.63 in.

• Approximate Ship Weight: 1.5 lbs


Material Compliance and Certifications

• Industry Standards: Manufactured to meet applicable industry standards for molded case circuit breakers used in 120/240VAC electrical distribution systems. Installation should follow National Electrical Code (NEC) requirements and all local electrical codes. Always confirm compatibility with the panel manufacturer’s specifications before installation.


Where It Works Best

• Compatible CH series load centers and panelboards
• Residential service panels requiring a 40A, 2-pole breaker
• Light commercial distribution systems
• Circuits serving 240V equipment such as HVAC units, water heaters, dryers, or similar loads
• Maintenance and replacement projects in existing electrical systems
