CH2100 - 100Amp Circuit Breaker

CH2100 - 100Amp Circuit Breaker

The CH2100 is a 100 Amp, 2-Pole Type CH bolt-on circuit breaker used to protect electrical systems from overloads and short-circuit faults. Found in everything from commercial buildings to industrial facilities, this breaker is a common choice for applications where a secure bolt-on connection and consistent circuit protection are required.

With a 100-amp rating, the CH2100 is often used on larger branch circuits, feeder circuits, HVAC equipment, and other electrical loads that require higher-capacity protection. The thermal magnetic trip mechanism combines two forms of protection in a single device. The thermal element responds to sustained overload conditions, while the magnetic element reacts to short-circuit events, helping disconnect faulted circuits before damage can spread through the system.

This breaker features a non-interchangeable trip unit, which keeps the protection settings fixed and eliminates the possibility of field adjustments. It also carries a 65kA interrupting rating at 240VAC and 14kA at 480VAC, making it suitable for installations where available fault current is a consideration. For HVAC applications, the CH2100 is HACR rated and designed for operation in 40°C ambient conditions on both 50Hz and 60Hz electrical systems.

Whether you're installing it in a distribution panel, protecting mechanical equipment, or replacing an existing breaker, the CH2100 offers a straightforward solution for applications that require 100 Amp, 2-pole overcurrent protection.

Key Features and Benefits

• 100 Amp current rating
• 2-pole configuration
• Type CH design
• Bolt-on mounting style
• Thermal magnetic trip mechanism
• Non-interchangeable trip unit
• 65kA interrupting rating at 240VAC
• 14kA interrupting rating at 480VAC
• HACR rated
• Suitable for 50Hz and 60Hz electrical systems
• Designed for operation in ambient temperatures up to 40°C


Technical Specifications

• Part Number: CH2100

• Type: CH

• Poles: 2

• Amperage Rating: 100A

• Trip Type: Thermal Magnetic

• Trip Unit: Non-Interchangeable

• Mounting Style: Bolt-On

• Interrupting Rating: 65kA @ 240VAC; 14kA @ 480VAC

• Frequency: 50/60Hz

• Temperature Rating: 40°C

• HACR Rated: Yes

• Height: 4.0 in
• Width: 2.0 in
• Depth: 2.63 in
• Approximate Dimensions: 2.0"W x 4.0"L x 2.63"D

• Approximate Shipping Weight: 2.75 lbs


Material Compliance and Certifications

• HACR Rated
• Thermal magnetic molded case circuit breaker
• Designed for use in compatible Type CH electrical distribution equipment
• Manufactured for applications requiring overcurrent and short-circuit protection


Where It Works Best

The CH2100 is commonly used in commercial facilities, manufacturing plants, warehouses, schools, healthcare buildings, HVAC systems, and electrical distribution equipment requiring 100 Amp, 2-pole protection. It is well suited for feeder circuits, larger branch circuits, mechanical equipment, and other installations where reliable overcurrent protection is needed.
