CH2070 - 70Amp Circuit Breaker

CH2070 - 70Amp Circuit Breaker

Introducing the CH2070 Circuit Breaker by Challenger, a top-tier solution engineered for both residential and commercial electrical systems. This advanced two-pole breaker boasts a robust 70-amp capacity, ensuring reliable performance and enhanced safety. Designed to operate efficiently across various electrical environments, it supports 480Y/277 Vac and 125/250 Vdc, making it a versatile choice for diverse applications. With an outstanding interrupting capacity of 65 kAIC at 240 Vac and 14 kAIC at 480Y/277 Vac, the CH2070 provides exceptional protection against potential electrical faults and overloads, guaranteeing peace of mind and operational continuity.

Key Features and Benefits:

• High Interrupting Capacity: Capable of 65 kAIC at 240 Vac and 14 kAIC at 480Y/277 Vac, offering superior fault protection.
• Versatile Voltage Ratings: Operates with both AC (480Y/277 Vac) and DC (125/250 Vdc) circuits, enhancing adaptability.
• Reliable Performance: Features fixed thermal and fixed magnetic trip types for consistent and dependable operation.

Technical Specifications:

• Frame Type: CH-Frame
• Trip Type: Fixed Thermal, Fixed Magnetic
• Number of Poles: 2
• Amperage Rating: 70 A
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Frequency: 50/60 Hz
• Interrupt Rating: 65 kAIC at 240 Vac, 14 kAIC at 480Y/277 Vac
• Dimensions: 2.63 in depth, 4 in height, 2 in width
• Weight: 1.15 lb

Material Compliance and Certifications:

• Certifications: UL Listed
• Compliances: Meets Federal Specifications Classification WC375B

Suitability:

• The CH2070 Circuit Breaker is ideal for a wide range of applications, from residential electrical panels to commercial distribution systems. Its high interrupting capacity and versatile voltage ratings make it suitable for environments with significant electrical loads and potential high fault currents. Whether for new installations or upgrades to existing systems, the CH2070 ensures unmatched protection and efficiency, making it a reliable choice for all your electrical protection needs.
