CH115AF - 15Amp Circuit Breaker

CH115AF - 15Amp Circuit Breaker

The CH115AF is a 15 Amp, 1-pole Type CHAF circuit breaker used in compatible CH load centers and panelboards that require Branch Feeder Type Arc Fault Circuit Interruption (AFCI) protection. For many replacement projects, matching the breaker type is just as important as matching the amp rating. The CH115AF is intended for applications where this specific CHAF configuration is required, helping maintain compatibility with the original electrical equipment.

This plug-on breaker combines standard overcurrent protection with Branch Feeder AFCI functionality. In addition to helping protect your branch circuits from overloads and short circuits, it is designed to detect certain arc fault conditions within branch wiring. With a 10kA interrupting rating at 120VAC, the CH115AF is commonly found in residential and light commercial electrical systems where AFCI protection is part of the original installation.

Electricians and maintenance personnel often encounter panels that have been in service for years and still require the same breaker style they were originally designed to use. The CH115AF fills that need by providing the proper form, fit, and function for compatible applications.

Key Features and Benefits

• 15 Amp current rating
• Single-pole circuit breaker
• Type CHAF configuration
• Branch Feeder Type Arc Fault Circuit Interruption (AFCI)
• Plug-on mounting style
• Helps protect branch circuits from overloads and short circuits
• Designed to detect specified branch feeder arc fault conditions
• Compatible with designated CH load centers and panelboards
• Maintains original equipment form, fit, and function
• Suitable for maintenance and replacement applications
• Built to last in properly maintained electrical systems


Technical Specifications

• Part Number: CH115AF

• Type: CHAF

• Poles: 1

• Amperage: 15 Amps

• Voltage Rating: 120 VAC

• Interrupting Capacity: 10kA @ 120VAC

• Protection Type: Branch Feeder Type Arc Fault Circuit Interruption (AFCI)

• Mounting Style: Plug-On
• Width: 0.75 in.
• Height: 4.63 in.
• Depth: 2.50 in.
• Approximate Dimensions: 0.75"W × 4.63"H × 2.50"D

• Approximate Ship Weight: 1.10 lbs.


Material Compliance and Certifications

• The CH115AF is intended for installation in compatible electrical equipment and should be installed in accordance with applicable electrical codes, manufacturer requirements, and local regulations.


Where It Works Best

The CH115AF is commonly used in:

• Residential electrical systems
• Light commercial electrical applications
• Compatible CH load centers and panelboards
• Branch circuits requiring AFCI protection
• Electrical maintenance and repair projects
• Replacement of existing CHAF breakers
• Applications where preserving original equipment configuration is important
