CH1040 - 40Amp Circuit Breaker

CH1040 - 40Amp Circuit Breaker

Introducing the Challenger CH1040 circuit breaker, a reliable and robust solution for your electrical protection needs. Designed for high performance and safety, this single-pole circuit breaker is ideal for residential, commercial, and light industrial applications. With a 40 ampere rating and a voltage capacity of 277 Vac or 125 Vdc, it ensures optimal protection and performance in various electrical systems.

Key Features and Benefits:

• High Interrupt Capacity: The CH1040 boasts a 14 kAIC rating at 277 Vac, providing superior protection against electrical faults.
• Fixed Thermal and Magnetic Trip: Ensures precise and reliable operation, safeguarding your electrical systems from overloads and short circuits.
• Compact and Lightweight Design: With dimensions of 2.63 inches in length, 4 inches in height, and 1 inch in width, and a weight of just 0.7 lbs, the CH1040 is easy to install and ideal for space-constrained environments.
• Versatile Application: Suitable for a variety of applications including residential, commercial, and light industrial settings.

Technical Specifications:

• Frame Type: CH-frame
• Amperage Rating: 40 A
• Voltage Rating: 277 Vac, 125 Vdc
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 14 kAIC at 277 Vac
• Number of Poles: Single-pole
• Trip Type: Fixed thermal, fixed magnetic
• Dimensions: Length 2.63 in, Height 4 in, Width 1 in
• Weight: 0.7 lbs

Material Compliance and Certifications:

• Compliance: Meets Federal Specifications Classification WC375B
• Certifications: UL Listed

Suitability:

• The CH1040 circuit breaker is perfect for those seeking a reliable and efficient solution for electrical protection. Its high interrupt capacity and precise tripping mechanism make it suitable for safeguarding circuits in homes, offices, and industrial settings. Whether you are upgrading an existing system or installing a new one, the CH1040 offers the reliability and performance you need to ensure the safety of your electrical infrastructure.
