CH1015 - 15Amp Circuit Breaker

CH1015 - 15Amp Circuit Breaker

The CH1015 is a 15 amp, 1-pole bolt-on circuit breaker designed for your branch circuit protection in commercial and industrial electrical systems. It's the type of breaker commonly found in panelboards, lighting panels, and distribution equipment where a secure bolt-on connection is required. When it's time to replace an existing breaker, matching the original specifications matters. The CH1015 provides the same basic configuration many facilities rely on for your everyday electrical distribution.

This breaker uses a thermal magnetic trip mechanism, a design that's been used for years to help protect circuits from overloads and short circuits. Rated 14kA at 277VAC, it's often used on lighting and control circuits where dependable overcurrent protection is needed.

What makes the CH1015 a practical choice is its straightforward design. There are no adjustable settings or interchangeable trip components to configure. Built to last, it's a breaker that's commonly used across a wide range of commercial, institutional, and industrial facilities.

Key Features and Benefits

• 15 amp current rating
• Single-pole design
• Bolt-on mounting configuration
• Thermal magnetic trip mechanism
• Non-interchangeable trip unit
• 14kA interrupting capacity at 277VAC
• HACR rated
• Rated for 50/60Hz operation
• Compact size for panelboard applications
• Form, fit, and functional replacement for compatible installations
• Built to last in commercial and industrial environments


Technical Specifications

• Part Number: CH1015

• Type: CH

• Circuit Breaker Type: Bolt-On Thermal Magnetic Circuit Breaker

• Amperage Rating: 15 Amps

• Poles: 1

• Voltage Rating: 277VAC

• A.I.C. Rating: 14kA @ 277VAC

• Frequency: 50/60Hz

• Operating Temperature: 40°C

• Trip Unit: Non-Interchangeable

• HACR Rated: Yes

• Dimensions:
  • Height: 4.00 in.
  • Width: 1.00 in.
  • Depth: 2.63 in.
• Approximate Shipping Weight: 2.25 lbs.


Material Compliance and Certifications

• HACR Rated
• Thermal magnetic overcurrent protection design
• Suitable for operation on 50/60Hz electrical systems
• Intended for installation in accordance with applicable electrical codes and equipment requirements
• Designed for commercial, industrial, and institutional electrical applications

Where It Works Best

The CH1015 is commonly used in office buildings, schools, healthcare facilities, retail locations, manufacturing plants, and other commercial properties. It's frequently installed in lighting panels, branch circuit applications, control circuits, and electrical distribution equipment where a compatible CH-type breaker is required.
