CCV2225 225A Circuit Breaker

CCV2225 225A Circuit Breaker

The Eaton CCV2225 Tenant Main Circuit Breaker is a high-performance solution designed to provide robust protection for residential and light commercial electrical systems. This circuit breaker, featuring a two-pole design and a current rating of 225A, is engineered to deliver reliable performance and ensure the safety of your electrical infrastructure. With a 10 kAIC interrupting capacity and compatibility with both copper and aluminum wires, the CCV2225 is an essential component for maintaining electrical system integrity.

Key Features and Benefits:

• High Current Rating: With a current rating of 225A, the CCV2225 is capable of handling substantial electrical loads, making it suitable for demanding applications.
• Reliable Protection: Designed to protect against overcurrent and short circuits, this circuit breaker ensures the safety and reliability of your electrical systems.
• Two-Pole Configuration: The two-pole design facilitates efficient load distribution, enhancing system stability and performance.
• Versatile Voltage Rating: Operating at 120/240 V, the CCV2225 is ideal for a wide range of residential and light commercial applications, providing flexibility and adaptability.
• Wide Wire Compatibility: This circuit breaker supports wire sizes ranging from #2/0 AWG to 300 kcmil for both copper and aluminum wires, ensuring easy installation and broad compatibility.

Technical Specifications:

• Amperage Rating: 225A
• Voltage Rating: 120/240 V
• Interrupting Capacity: 10 kAIC
• Number of Poles: Two-pole
• Wire Size: #2/0 AWG - 300 kcmil Cu/Al
• Mounting Type: Type ECC unit enclosures
• Product Dimensions: Length: 8 in, Height: 5.5 in, Width: 4.5 in
• Product Weight: 2.5 lbs

Material Compliance and Certifications:

• Compliance: The Eaton CCV2225 meets the highest industry standards, ensuring safe and reliable performance. It is UL 489 Listed, providing assurance of its compliance with global safety and performance regulations. The standard lugs (wire connectors) are suitable for both copper and aluminum wires, enhancing its versatility and ease of installation.

Suitability:

• The CCV2225 circuit breaker is ideal for residential and light commercial applications where reliable circuit protection is essential. Its high current rating and versatile voltage ratings make it an excellent choice for protecting electrical systems in homes, apartments, and small businesses. The compact and lightweight design also facilitates easy installation and integration into existing electrical panels and systems.

Invest in the Eaton CCV2225 Tenant Main Circuit Breaker for advanced protection and reliable performance in your electrical systems.
