CCV2100 - 100Amp Circuit Breaker

CCV2100 - 100Amp Circuit Breaker

The Eaton CCV2100 Tenant Main Circuit Breaker is a high-performance solution designed to provide robust protection for residential and light commercial electrical systems. This circuit breaker is engineered with precision and reliability, ensuring safe operation under various conditions. With a 100A current rating, two-pole configuration, and an interrupting capacity of 10 kAIC, the CCV2100 is an essential component for maintaining the integrity and safety of your electrical infrastructure.

Key Features and Benefits:

• Reliable Protection: The CCV2100 offers dependable protection against overcurrent and short circuits, safeguarding your electrical systems from potential damage.
• High Interrupting Capacity: With an interrupting capacity of 10 kAIC, this circuit breaker is capable of handling high fault currents, ensuring robust performance in demanding environments.
• Two-Pole Configuration: The two-pole design allows for efficient load distribution, enhancing system stability and reliability.
• Versatile Voltage Rating: Operating at 120/240 V, the CCV2100 is suitable for a wide range of residential and light commercial applications, providing flexibility and adaptability in various settings.
• Wide Wire Compatibility: The CCV2100 supports wire sizes ranging from #2/0 AWG to 300 kcmil for both copper and aluminum wires, ensuring compatibility with different installation requirements.

Technical Specifications:

• Amperage Rating: 100A
• Voltage Rating: 120/240 V
• Interrupting Capacity: 10 kAIC
• Number of Poles: Two-pole
• Wire Size: #2/0 AWG - 300 kcmil Cu/Al
• Mounting Type: Type ECC unit enclosures
• Product Dimensions: Length: 7.7 in x Height: 5.4 in x Width: 4.5 in
• Product Weight: 3 lbs

Material Compliance and Certifications:

• Compliance: The Eaton CCV2100 meets the highest industry standards, ensuring safe and reliable performance. It is UL 489 Listed, providing assurance of its compliance with global safety and performance regulations. The standard lugs (wire connectors) are suitable for both copper and aluminum wires, enhancing its versatility and ease of installation.

Suitability:

• The CCV2100 circuit breaker is ideal for residential and light commercial applications where reliable circuit protection is essential. Its high interrupting capacity and versatile voltage ratings make it an excellent choice for protecting electrical systems in homes, apartments, and small businesses. The compact and lightweight design also facilitates easy installation and integration into existing electrical panels and systems.
