CC3100 - 100Amp Circuit Breaker

CC3100 - 100 Amp Circuit Breaker

If you’re replacing a 100-amp, 3-pole breaker in a compatible CC frame panel, the CC3100 molded case circuit breaker is built to match the original form, fit, and function of your existing equipment. It’s rated 100 amps with an interrupting capacity of 10kA at 240VAC, making it suitable for many standard commercial and light industrial electrical distribution systems. This breaker features a non-interchangeable (fixed) trip unit, meaning the trip settings are factory set and not field-adjustable. That simplifies installation and helps ensure the breaker operates within its designed protection range. The molded case housing encloses and protects the internal components, supporting long-term use in properly maintained electrical environments. When your goal is maintaining compatibility in an existing system—not redesigning it—the CC3100 provides the correct ratings and configuration to get the job done.

Key Features and Benefits

• 100 Amp Rating: Designed for circuits requiring 100A overcurrent protection.
• 3 Poles: Suitable for three-phase applications.
• 10kA @ 240VAC A.I.C. Rating: Interrupting capacity aligned with common 240V systems.
• CC Frame Type: Matches equipment designed for CC frame breakers.
• Fixed (Non-Interchangeable) Trip Unit: Factory-set protection for consistent operation.
• Molded Case Design: Fully enclosed construction intended for long service life.

Technical Specifications

• Part Number: CC3100

• Product Type: Molded Case Circuit Breaker

• Frame Type: CC

• Amperage: 100A

• Poles: 3

• Voltage Rating: 240VAC

• Interrupting Capacity: 10kA @ 240VAC

• Trip Type: Non-Interchangeable (Fixed)

• Approximate Height: 6.0 inches

• Shipping Weight: 4.13 lbs


Material Compliance and Certifications

• Industry Standards: Manufactured to meet applicable industry standards for molded case circuit breakers used in low-voltage power distribution systems.
• Installation Requirements: Installation should be performed according to the National Electrical Code (NEC) and all local electrical regulations to maintain compliance and safety.

Where It Works Best

• Commercial buildings operating on 240VAC three-phase systems
• Industrial panels using CC frame breakers
• Maintenance replacements in existing distribution equipment
• Facilities needing a 100A, 3-pole breaker with a 10kA interrupting rating
