CC2225 - 225Amp Circuit Breaker

CC2225 - 225 Amp Circuit Breaker

The CC2225 circuit breaker is a 2-pole, 225-amp molded case breaker designed for use in 240VAC electrical systems. Built on a CC frame, it provides dependable overcurrent and short-circuit protection for panels and distribution equipment that require this specific frame size and rating. If you’re maintaining or repairing an existing system, this breaker is intended as a direct form, fit, and function replacement for other CC frame 225A, 2-pole units with a 10kA interrupting rating at 240VAC. With its straightforward design and solid internal components, the CC2225 is built to last in commercial and light industrial settings. It helps protect wiring, equipment, and connected loads by interrupting overloads and fault conditions within its rated capacity. Always confirm compatibility with your panel and verify that voltage and interrupting ratings meet your system requirements before installation.

Key Features and Benefits

• 225 Amp Rating: Supports circuits requiring 225A overcurrent protection.
• 2 Poles: Designed for 240VAC applications across two phases.
• 10kA A.I.C. @ 240VAC: Rated to safely interrupt up to 10,000 amps of fault current.
• CC Frame Type: Matches equipment designed for CC frame breakers.
• Form, Fit, Function Replacement: Suitable for replacing existing breakers with the same specifications.
• Built to Last: Constructed for consistent performance in everyday operating conditions.


Technical Specifications

• Part Number: CC2225

• Amperage: 225A

• Poles: 2

• Voltage Rating: 240VAC

• Interrupting Capacity: 10kA @ 240VAC

• Frame Type: CC

• Approx. Shipping Weight: 2.75 lbs

• Approx. Shipping Height: 6.0 inches


Material Compliance and Certifications

• Industry Standards: The CC2225 circuit breaker is manufactured to meet applicable industry standards for molded case circuit breakers. When installed in properly rated and compatible equipment, it is intended to comply with relevant UL requirements and National Electrical Code (NEC) guidelines. Installation should always be performed according to local electrical codes and by qualified personnel.


Where It Works Best

• Commercial panelboards
• Light industrial facilities
• Service and feeder applications rated 240VAC
• Maintenance projects involving CC frame equipment
• Replacement of existing 225A, 2-pole breakers with a 10kA rating
