CC2175 - 175Amp Circuit Breaker

CC2175 - 175Amp Circuit Breaker

The CC2175 is a 175 Amp, 2-pole molded case circuit breaker designed for you to use in electrical distribution systems operating at 240VAC. This Type CC circuit breaker is commonly found in commercial and industrial installations where a breaker with matching ratings and configuration is required. Its primary function is to provide overcurrent and short-circuit protection for your electrical circuits and connected equipment.

Rated for 10kA interrupting capacity at 240VAC, the CC2175 is often used in distribution panels, switchboards, feeder circuits, and other power distribution equipment. When you're servicing existing electrical systems, matching the original breaker type, amperage rating, voltage rating, and pole configuration is often an important part of maintaining equipment compatibility. The CC2175 is frequently selected for applications where a Type CC 175 Amp circuit breaker is specified and where form, fit, and function need to remain consistent with the original installation.

Its molded case construction and compact dimensions allow it to fit within compatible equipment designed for this breaker style. Like many breakers used in long-serving electrical systems, the CC2175 was built to last and continues to be used in maintenance and replacement projects across a wide range of facilities.

Important Note: If this product does not show price and availability, check the "Related Items" below

Key Features and Benefits

• 175 Amp current rating
• 2-pole configuration
• Type CC molded case circuit breaker
• 10kA interrupting capacity at 240VAC
• Designed for overload and short-circuit protection
• Supports form, fit, and functional replacement requirements
• Suitable for compatible commercial and industrial electrical systems
• Compact design for installation in designated equipment
• Commonly used in electrical distribution and feeder circuit applications
• Built for long-term service in properly maintained installations

Technical Specifications

• Part Number: CC2175

• Type: CC

• Amperage Rating: 175 Amps

• Poles: 2

• Voltage Rating: 240VAC

• A.I.C. Rating: 10kA @ 240VAC

• Dimensions:
  • Width: 2.75 in.
  • Height: 6.00 in.
  • Depth: 3.06 in.
• Approximate Dimensions: 2.75" W × 6.00" H × 3.06" D

• Approximate Shipping Weight: 4.5 lbs


Material Compliance and Certifications

• Molded case circuit breaker construction
• Designed for overcurrent and short-circuit protection
• Intended for use in compatible electrical distribution equipment
• Installation should follow applicable electrical codes and equipment requirements
• Verify ratings and compatibility before installation

Where It Works Best

The CC2175 is commonly used in commercial buildings, industrial facilities, manufacturing equipment, electrical distribution panels, switchboards, and feeder circuits requiring a 175 Amp, 2-pole circuit breaker rated for 240VAC operation. It is particularly suited for maintenance and replacement applications where a Type CC circuit breaker is specified and maintaining compatibility with existing equipment is important.
