CBB3060H - 60Amp Circuit Breaker

CBB3060H - 60Amp Circuit Breaker

The CBB3060H is a 60 amp, 3-pole bolt-on circuit breaker used to protect electrical systems from overloads and short circuits. It's commonly installed in commercial buildings, industrial facilities, and HVAC systems where three-phase power distribution is required.

With a 10kA interrupting rating at 240VAC, this molded case circuit breaker is designed to interrupt fault currents before they can damage equipment or wiring. The bolt-on mounting style provides a secure connection inside compatible panelboards, making it a good fit for applications where dependable circuit protection is important.

The CBB3060H is also HACR rated, making it suitable for heating, air conditioning, and refrigeration equipment. Its compact size helps simplify installation in compatible panels, while the 60-amp rating makes it useful for a wide range of equipment and distribution circuits.

Whether you're replacing an existing breaker during routine maintenance or matching equipment specifications for a new project, the CBB3060H provides the overcurrent protection needed to help keep electrical systems operating safely.

Key Features and Benefits

• 60 amp current rating
• 3-pole design for three-phase electrical systems
• Bolt-on mounting for a secure panel connection
• 10kAIC rating at 240VAC
• HACR rated for HVAC and refrigeration applications
• Molded case construction
• Rated for operation in 40°C ambient conditions
• Compact footprint for efficient use of panel space

Technical Specifications

• Part Number: CBB3060H

• Type: CBB

• Poles: 3

• Amperage: 60 Amps

• Voltage Rating: 240VAC

• Interrupting Capacity: 10kAIC @ 240VAC

• Mounting Style: Bolt-On

• Breaker Type: Molded Case Circuit Breaker

• HACR Rated: Yes

• Temperature Rating: 40°C

• Approximate Weight: 2.50 lbs

• Dimensions:
  • Height: 3.41 in
  • Width: 3.00 in
  • Depth: 2.92 in
• Approximate Dimensions: 3.00" W x 3.41" H x 2.92" D


Material Compliance and Certifications

• HACR (Heating, Air Conditioning, and Refrigeration) Rated
• Designed for overcurrent and short-circuit protection
• Molded case circuit breaker construction for use in compatible electrical systems

Where It Works Best

The CBB3060H is frequently used in electrical distribution systems, HVAC equipment, motor circuits, commercial facilities, and industrial applications requiring a 60 amp 3-pole circuit breaker. It's particularly useful where a bolt-on molded case circuit breaker is needed to provide dependable protection for three-phase circuits operating at 240VAC.
