CBB2090 - 90Amp Circuit Breaker

CBB2090 - 90Amp Circuit Breaker

The CBB2090 is a 90 amp, 2-pole bolt-on molded case circuit breaker for use in 120/240VAC electrical systems. Its purpose is straightforward: when a circuit sees an overload or short circuit, the breaker trips and shuts off power to help protect wiring and connected equipment.

A breaker in this size is often used on larger electrical loads. You'll commonly find 90 amp 2-pole breakers serving HVAC equipment, air conditioning condensers, refrigeration systems, compressors, subpanels, and motor-driven equipment. Because it protects both legs of a 120/240VAC circuit, it's a common sight in commercial buildings, warehouses, schools, office spaces, apartment properties, and light industrial facilities.

The bolt-on design allows the breaker to be secured in compatible panelboards, which is why it's frequently used in both replacement work and new installations. The CBB2090 carries a 10kA interrupting rating at 120/240VAC and is HACR rated for heating, air conditioning, and refrigeration applications. Its compact footprint can also be helpful when working in existing equipment where panel space is already spoken for.

If you're replacing a breaker and need a 90 amp, 2-pole bolt-on circuit breaker, this model is built for the job without unnecessary extras or complications. It does what a circuit breaker is supposed to do—protect the circuit and help keep equipment operating as intended.

Key Features and Benefits

• 90 amp rating for larger branch circuits and equipment loads
• Two-pole configuration for 120/240VAC applications
• Bolt-on mounting for secure installation in compatible panelboards
• 10kA interrupting capacity at 120/240VAC
• HACR rated for HVAC and refrigeration equipment
• Molded case construction for overcurrent protection
• Compact size helps conserve panel space
• Rated for operation in ambient temperatures up to 40°C


Technical Specifications

• Part Number: CBB2090

• Type: CBB

• Poles: 2

• Amperage: 90 Amps

• Voltage Rating: 120/240VAC

• Interrupting Capacity (A.I.C.): 10kA @ 120/240VAC

• Mounting Style: Bolt-On

• Circuit Breaker Type: Molded Case Circuit Breaker

• HACR Rated: Yes

• Ambient Temperature Rating: 40°C

• Dimensions:
  • Width: 2.00 in.
  • Height: 3.41 in.
  • Depth: 2.92 in.
• Approximate Dimensions: 2.00"W x 3.41"H x 2.92"D

• Approximate Ship Weight: 2.00 lbs.


Material Compliance and Certifications

• HACR Rated
• Molded case circuit breaker construction
• Intended for branch circuit and electrical distribution applications
• Suitable for installation in compatible bolt-on electrical systems
• Rated for operation in ambient temperatures up to 40°C


Where It Works Best

The CBB2090 is commonly used in commercial buildings, warehouses, schools, office facilities, apartment complexes, retail locations, and light industrial properties. Typical applications include HVAC systems, air conditioning equipment, refrigeration units, compressors, motor circuits, feeders, subpanels, and electrical distribution systems requiring a 90 amp, 2-pole circuit breaker operating on 120/240VAC power.
