CBB2060 - 60Amp Circuit Breaker

CBB2060 - 60Amp Circuit Breaker

Upgrade your electrical infrastructure with the Challenger CBB2060 Circuit Breaker, a robust solution for both residential and commercial applications. Designed to ensure safety and reliability, this two-pole circuit breaker provides superior protection for your electrical systems. Its bolt-on mounting mechanism facilitates easy installation, while the thermal magnetic trip unit delivers consistent performance under various load conditions. The CBB2060, previously known under the Eaton BAB2060 designation, boasts a high interrupting capacity of 10kAIC, ensuring it can handle significant fault currents without compromising system integrity. Engineered with non-interchangeable components and rated for 60A at 120/240V, this circuit breaker is ideal for high-intensity discharge applications, making it a versatile addition to any electrical setup.

Key Features and Benefits:

• High Performance: With a 10kAIC interrupting capacity, this circuit breaker is built to handle high fault currents effectively, ensuring maximum safety.
• Thermal Magnetic Trip: Combines thermal and magnetic trip elements to provide reliable circuit protection against overloads and short circuits.
• Durable Construction: Built to last with high-quality materials and a robust design, ensuring longevity and consistent performance.
• Ease of Installation: Bolt-on mounting system allows for quick and secure installation, reducing downtime and labor costs.
• Versatile Use: Suitable for both residential and commercial applications, particularly high-intensity discharge applications.

Technical Specifications:

• Amperage Rating: 60A
• Voltage Rating: 120/240V
• Interrupting Capacity: 10kAIC
• Number of Poles: 2
• Mounting Type: Bolt-on
• Trip Type: Thermal Magnetic
• Dimensions: 2.00"W x 3.41"L x 2.92"D
• Weight: 2.00 lb

Material Compliance and Certifications:

• Certifications: UL Listed, CSA Certified
• Standards: Compliant with industry standards ensuring safe and reliable operation.

Suitability:

• The Challenger CBB2060 Circuit Breaker is ideally suited for a range of applications, including residential panels, commercial buildings, and high-intensity discharge systems. Its robust design and high interrupting capacity make it an excellent choice for protecting electrical circuits in demanding environments. Whether upgrading an existing system or installing a new one, the CBB2060 provides the reliability and performance needed to keep your electrical systems running smoothly.
