CBB2015 - 15Amp Circuit Breaker

CBB2015 - 15Amp Circuit Breaker

The CBB2015 is a 15 amp, 2-pole bolt-on molded case circuit breaker used in 120/240VAC electrical systems where branch circuit protection is required. It helps protect your wiring and connected equipment by interrupting power during overloads and short-circuit conditions. The two-pole design allows it to protect both legs of a 120/240VAC circuit, making it suitable for a variety of commercial and industrial applications.

This breaker features a 10kA interrupting rating at 120/240VAC and a bolt-on mounting design for installation in compatible electrical equipment. It is also HACR rated, making it suitable for many heating, air conditioning, and refrigeration applications.

Whether you're replacing an existing breaker during maintenance or being installed as part of an electrical upgrade, the CBB2015 provides straightforward, reliable protection for everyday electrical distribution applications.

Key Features and Benefits

• 15 amp rating for branch circuit protection
• Two-pole design for 120/240VAC systems
• Bolt-on mounting for a secure connection
• 10kA interrupting capacity at 120/240VAC
• HACR rated for HVAC and refrigeration equipment
• Compact size for use in compatible panelboards and distribution equipment
• Rated for operation in ambient temperatures up to 40°C
• Molded case construction for dependable overcurrent protection


Technical Specifications

• Part Number: CBB2015

• Type: CBB

• Poles: 2

• Amperage: 15 Amps

• Voltage Rating: 120/240VAC

• Interrupting Capacity (A.I.C.): 10kA @ 120/240VAC

• Mounting Style: Bolt-On

• Circuit Breaker Type: Molded Case Circuit Breaker

• HACR Rated: Yes

• Ambient Temperature Rating: 40°C

• Dimensions:
  • Width: 2.00 in.
  • Height: 3.41 in.
  • Depth: 2.92 in.
• Approximate Dimensions: 2.00"W x 3.41"L x 2.92"D

• Approximate Ship Weight: 2.00 lbs


Material Compliance and Certifications

• HACR Rated
• Molded case circuit breaker construction
• Intended for branch circuit and electrical distribution applications
• Suitable for use in compatible bolt-on electrical systems


Where It Works Best

The CBB2015 is commonly used in commercial buildings, warehouses, schools, manufacturing facilities, and other properties that utilize 120/240VAC electrical systems. Typical applications include HVAC equipment, refrigeration systems, lighting circuits, control panels, and general electrical distribution systems requiring a 15 amp, 2-pole circuit breaker.
