CBB1030 - 30Amp Circuit Breaker

CBB1030 - 30Amp Circuit Breaker

Introducing the Challenger CBB1030 Quicklag Industrial Thermal-Magnetic Circuit Breaker, a highly reliable and efficient solution for protecting electrical circuits in industrial and commercial environments. Designed to provide superior overcurrent protection, this single-pole circuit breaker boasts a 30A rating and a high interrupting capacity of 10 kAIC, ensuring robust performance under demanding conditions. Operating at 120/240 volts, the CBB1030 is ideal for high-intensity discharge applications. Its thermal-magnetic trip mechanism ensures precise protection by combining thermal overload sensing with instantaneous magnetic response, making it an essential component for safeguarding electrical systems against overloads and short circuits.

Key Features and Benefits:

• High Performance: Rated at 30A with a 10 kAIC interrupting capacity, ensuring reliable protection against electrical faults.
• Versatile Application: Suitable for use in 120/240V systems, making it perfect for various industrial and commercial applications.
• Durable Design: Constructed with high-quality materials for long-lasting durability and performance.
• Easy Installation: Features Quicklag technology for fast and secure installation, with ring or spade lug terminals.
• Thermal-Magnetic Trip: Provides accurate overcurrent protection with a combination of thermal and magnetic trip mechanisms.

Technical Specifications:

• Amperage: 30A
• Interrupting Capacity: 10 kAIC
• Voltage Rating: 120/240V
• Poles: Single-pole
• Terminals: Ring or spade lug
• Trip Type: Thermal-Magnetic
• Dimensions: 1.00"W x 3.41"L x 2.92"D
• Weight: 1.75 lb

Material Compliance and Certifications:

• Certifications: UL Listed, CSA Certified
• Compliance: HACR rated for heating, air conditioning, and refrigeration applications

Suitability:

• The Challenger CBB1030 circuit breaker is designed for high-intensity discharge applications in industrial and commercial settings. Its robust design and reliable protection features make it an ideal choice for use in load centers, panelboards, and other electrical distribution systems. Ensuring the safety and efficiency of your electrical installations, this circuit breaker is perfect for protecting wiring and equipment from potential damage caused by overloads and short circuits.
