CBB1015 - 15Amp Circuit Breaker

CBB1015 - 15Amp Circuit Breaker

Introducing the Challenger CBB1015 Quicklag Industrial Thermal-Magnetic Circuit Breaker, a top-tier solution for safeguarding electrical circuits in industrial and commercial settings. This single-pole circuit breaker offers exceptional protection with its 15-ampere rating and a high interrupting capacity of 10 kAIC, ensuring robust performance and reliability.

Key Features and Benefits:

• Robust Protection: With a 15A rating and 10 kAIC interrupting capacity, this circuit breaker ensures reliable protection against overloads and short circuits.
• Durable Construction: Built with high-quality materials for long-lasting performance and reliability.
• Easy Installation: Features ring or spade lug terminals for secure and straightforward connections.

Technical Specifications:

• Amperage: 15A
• Interrupting Capacity: 10 kAIC
• Voltage Rating: 120V
• Poles: Single-pole
• Dimensions: 1.00"W x 3.41"L x 2.92"D
• Weight: 1.75 lb

• Additional Features: HACR rated, Bolt-on Molded Case Circuit Breaker, 40ºC

Material Compliance and Certifications:

• Certifications: UL Listed, CSA Certified

Suitability:

• The Challenger CBB1015 circuit breaker is perfect for high-intensity discharge applications in industrial and commercial environments. Its robust design and reliable protection features make it suitable for use in load centers, panelboards, and other electrical distribution systems. Ideal for protecting wiring and equipment from overloads and short circuits, this circuit breaker ensures the safety and efficiency of your electrical installations.
