C135 - 35Amp Circuit Breaker

C135 - 35Amp Circuit Breaker

The C135 is a 35 Amp single-pole circuit breaker used in compatible Type C electrical panels. It's the kind of breaker you'll typically find protecting dedicated equipment circuits and other loads that need more capacity than a standard 20 or 30 Amp circuit. When an overload or short circuit occurs, the breaker trips and cuts power to the circuit, helping prevent damage to wiring and connected equipment.

For many panel repairs, the challenge isn't figuring out the amp rating—it's finding the right breaker that matches the panel. That's why replacement projects often start with the part number.

Its HACR rating makes it suitable for approved heating, air conditioning, and refrigeration applications, but you'll also find breakers like the C135 protecting dedicated equipment, utility circuits, and other branch circuit loads. Most of the time, a breaker does its work quietly in the background. When a fault occurs, though, it's expected to respond immediately. That's exactly the role the C135 is built to fill.

Key Features and Benefits

• 35 Amp single-pole circuit breaker
• Type C plug-on mounting design
• HACR rated for approved HVAC and refrigeration applications
• Helps protect against overloads and short-circuit conditions
• 10kA interrupting capacity at 120VAC
• Suitable for dedicated and branch circuit protection
• Compact size for installation in compatible panels
• Common choice for maintenance and replacement projects
• Suitable for residential, commercial, and light industrial applications
• Designed for use in compatible Type C electrical equipment


Technical Specifications

• Part Number: C135

• Type: C

• Amperage Rating: 35 Amps

• Poles: 1

• Voltage Rating: 120VAC

• Interrupting Capacity: 10kA @ 120VAC

• Mounting Style: Plug-On

• HACR Rated: Yes

• Dimensions: 1.00"W × 2.88"H × 2.56"D

• Width: 1.00 in.

• Height: 2.88 in.

• Depth: 2.56 in.

• Approximate Shipping Weight: 0.50 lbs.


Material Compliance and Certifications

• HACR rated for approved heating, air conditioning, and refrigeration applications
• Manufactured for use in compatible electrical distribution equipment
• Intended for overcurrent protection applications
• Built to applicable industry manufacturing standards
• Installation should comply with applicable electrical codes and regulations
• Compatibility should be verified before installation


Where It Works Best

• The C135 is commonly used in residential, commercial, and light industrial electrical systems that require a 35 Amp single-pole breaker. Typical applications include dedicated equipment circuits, HVAC control systems, refrigeration equipment, workshops, utility rooms, mechanical spaces, and general branch circuit protection. It is often installed during breaker replacement projects, panel maintenance, and electrical repairs where maintaining compatibility with existing Type C equipment is important.
