C115 - 15Amp Circuit Breaker

C115 - 15Amp Circuit Breaker

The C115 is a 15 Amp, single-pole plug-on circuit breaker used to protect 120-volt branch circuits from overloads and short circuits. It's the type of component most people never think about until a breaker needs to be replaced or a panel is being serviced. Once installed in a compatible panel, the C115 helps keep your electrical circuits protected by interrupting power when current levels exceed safe operating limits.

For electricians and maintenance professionals, finding the correct replacement breaker is often about more than matching the amperage.

Electrical systems depend on dozens of individual components working together, and circuit breakers are among the most important. The C115 provides a simple, dependable way to protect lighting circuits, receptacles, and other everyday branch circuits. With a 10kA interrupting capacity at 120VAC, it is well suited for many residential, commercial, and light industrial electrical systems.

Key Features and Benefits

• 15 Amp single-pole circuit breaker
• Type C breaker for compatible electrical panels
• Plug-on mounting design
• HACR rated for approved HVAC and refrigeration applications
• Helps protect against overloads and short-circuit faults
• 10kA interrupting capacity at 120VAC
• Compact size for efficient use of panel space
• Suitable for branch circuit protection
• Commonly used for maintenance and replacement projects
• Designed for reliable everyday operation


Technical Specifications

• Part Number: C115

• Type: C

• Amperage Rating: 15 Amps

• Poles: 1

• Voltage Rating: 120VAC

• Interrupting Capacity: 10kA @ 120VAC

• Mounting Style: Plug-On

• HACR Rated: Yes

• Dimensions: 1.00"W × 2.88"H × 2.56"D

• Width: 1.00 in.

• Height: 2.88 in.

• Depth: 2.56 in.

• Approximate Shipping Weight: 1.75 lbs.


Material Compliance and Certifications

• HACR rated for approved heating, air conditioning, and refrigeration applications
• Manufactured for use in compatible electrical distribution equipment
• Intended for overcurrent protection applications
• Installation should comply with applicable electrical codes and regulations
• Compatibility should be verified before installation


Where It Works Best

• The C115 is commonly used in residential, commercial, and light industrial electrical systems that require a 15 Amp single-pole breaker. Typical applications include lighting circuits, receptacle circuits, utility areas, office spaces, HVAC control circuits, and general-purpose branch circuit protection.
