BW2150 - 150Amp Circuit Breaker

BW2150 - 150Amp Circuit Breaker

The BW2150 is a 150 Amp, two-pole main circuit breaker built for residential electrical systems that require reliable service entrance protection. Installed as the primary disconnect in compatible equipment, it helps you protect the electrical system from overloads and short circuits while allowing power to be safely disconnected when needed.

In many homes, the main breaker is one of the hardest-working components in the panel. That's why selecting the correct replacement matters. The BW2150 combines a two-pole configuration with a 240VAC rating and a 10kA interrupting capacity, making it suitable for a wide range of residential service applications. Whether you're replacing an existing breaker during maintenance or updating equipment as part of a service upgrade, matching the breaker's amperage, type, and electrical ratings is essential for proper operation.

Key Features and Benefits

• 150 Amp main residential circuit breaker
• Two-pole design for 240VAC applications
• Functions as a main disconnect breaker
• 10kA interrupting capacity
• Helps protect against overloads and short circuits
• Suitable for compatible BW breaker applications
• Supports residential electrical service equipment
• Common replacement option during panel maintenance and upgrades
• Compact construction for use in compatible installations


Technical Specifications

• Part Number: BW2150

• Type: BW

• Application: Main Residential Circuit Breaker

• Amperage Rating: 150 Amps

• Poles: 2

• Voltage Rating: 240VAC

• Interrupt Rating: 10kA @ 240VAC

• Dimensions:
  • Width: 5.25 in.
  • Height: 4.25 in.
  • Depth: 3.00 in.
• Dimensions: 5.25"W × 4.25"H × 3.00"D

• Approximate Shipping Weight: 3.5 lbs


Material Compliance and Certifications

• Manufactured for use in compatible electrical distribution equipment
• Designed for residential overcurrent protection applications
• Built to meet applicable industry manufacturing standards


Where It Works Best

• The BW2150 is typically found in residential electrical systems where a 150 Amp main breaker is required. Common applications include single-family homes, duplexes, condominiums, townhomes, and similar residential properties with 240VAC service.
• Because it serves as the main breaker, the BW2150 is well suited for installations where dependable whole-panel protection and disconnect capability are required. It is often selected by electricians and maintenance professionals working on residential power distribution systems that utilize BW-type breakers.
