BW2125 - 125Amp Circuit Breaker

BW2125 - 125Amp Circuit Breaker

The BW2125 is a 125 Amp, 2-pole main residential circuit breaker designed for 240-volt electrical service applications. Commonly installed as the primary disconnect and overcurrent protection device in residential electrical panels, it helps protect your electrical systems from overloads and short circuits while supporting the power requirements of modern homes.

With a 125 Amp rating and a 10kA interrupting capacity at 240 VAC, the BW2125 is frequently used in residential service equipment, panel replacements, service upgrades, and new construction projects. Its two-pole design allows it to disconnect both legs of the electrical service when required, making it suitable for main breaker applications where full system disconnect capability is needed.

The compact footprint allows installation in compatible equipment without sacrificing panel space.

Whether your replacing an existing main breaker or completing a panel upgrade, the BW2125 provides the ratings and functionality commonly required in residential electrical service applications.

Key Features and Benefits

• 125 Amp main residential circuit breaker
• Two-pole configuration for 240 VAC systems
• Provides overload and short-circuit protection
• 10kA interrupting rating at 240 VAC
• Suitable for main disconnect applications
• Compact design for compatible electrical panels
• Commonly used for service upgrades and panel replacements
• Supports residential power distribution systems
• Designed for residential electrical service equipment


Technical Specifications

• Part Number: BW2125

• Type: BW

• Product Category: Main Residential Circuit Breaker

• Amperage Rating: 125 Amps

• Poles: 2

• Voltage Rating: 240 VAC

• Interrupting Rating (A.I.C.): 10kA @ 240 VAC

• Dimensions:
  • Width: 5.25 in.
  • Height: 4.25 in.
  • Depth: 3.00 in.
• Dimensions: 5.25"W x 4.25"L x 3.00"D

• Approximate Shipping Weight: 3.5 lbs.


Material Compliance and Certifications

• The BW2125 is intended for use in compatible residential electrical distribution equipment and should be installed in accordance with manufacturer recommendations and applicable electrical codes.
• For specific compliance information, certifications, listing details, and installation requirements, consult the manufacturer's documentation and local code requirements before installation.


Where It Works Best

• The BW2125 is commonly installed as a main breaker in residential service panels requiring 125 Amp protection. Typical applications include single-family homes, residential service upgrades, panel replacements, remodeling projects, and new construction.
• It is frequently used where a two-pole main disconnect is required to protect and isolate a home's electrical distribution system. The 125 Amp rating makes it suitable for residences that require higher-capacity electrical service while maintaining standard residential panel configurations.
