BRH290 - 90Amp Circuit Breaker

BRH290 - 90Amp Circuit Breaker

The Eaton BRH290 is a premium two-pole thermal magnetic circuit breaker designed for robust electrical safety and efficiency. Engineered with a 90 A current rating and a substantial interrupt rating of 22 kAIC, this circuit breaker ensures protection against high voltage faults in residential and commercial setups. It operates on a voltage rating of 120/240V, making it versatile for various electrical applications.

Key Features and Benefits:

• Robust Amperage Capacity: With a 90 ampere load capacity, the BRH290 is built to support higher current loads, suitable for a variety of demanding electrical applications.
• High Interrupt Rating: The 22 kAIC interrupt capacity provides exceptional protection, enhancing safety by effectively managing high fault currents.
• Compact and Efficient Design: The 1-inch plug-on design facilitates easy installation and integration with Type BR load centers, optimizing space and enhancing system organization.
• Versatile Wiring Compatibility: Accommodates #4-1/0 AWG Cu/Al wires, offering flexibility in connection choices to suit different wiring needs.

Technical Specifications:

• Type: BR 1-Inch plug-on circuit breaker
• Poles: Two-pole
• Amperage: 90 A
• Voltage: 120/240 V
• Trip Type: Common breaker trip
• Interrupt Rating: 22 kAIC
• Wire Size: #4-1/0 AWG Cu/Al

Material Compliance and Certifications:

• Compliance: Compliant with Federal Specifications Classification W-C376, ensuring reliability and quality.
• Certified by UL: Certified under standard 490, which guarantees that the product meets stringent safety and performance criteria.

Suitability:

• Ideal for residential and commercial power distribution systems, the BRH290 enhances system reliability and protection. It is specifically designed for use with Eaton's Type BR load centers, commonly employed in a variety of installations where efficiency and safety are priorities.

With its advanced features and robust performance specifications, the Eaton BRH290 is a dependable choice for ensuring electrical circuit integrity and protection against overloads and short circuits.
