BR390 90A Circuit Breaker

BR390 90A Circuit Breaker

Enhance your electrical system's reliability with the Eaton BR390 Thermal Magnetic Circuit Breaker. Designed for safety and efficiency, this robust three-pole breaker is compatible with Type BR Loadcenters and ensures a secure connection with a plug-on mounting method. Rated for 90 amps and capable of interrupting up to 10,000 amps under fault conditions, the BR390 is an essential safeguard for your high-demand electrical circuits.

Key Features and Benefits:

• High Capacity: With a 90A rating, it accommodates significant electrical loads, making it ideal for large residential or commercial spaces.
• Triple Pole Protection: Offers comprehensive protection by covering multiple circuits simultaneously, enhancing overall system safety.
• Easy Installation: The plug-on design allows for quick and straightforward installation, reducing downtime and labor costs.
• Wide Wire Range: Compatible with wires from #4 to 1/0 AWG, both Cu and Al, providing flexibility and compatibility with various wiring setups.

Technical Specifications:

• Voltage Rating: 240 V
• Interrupt Rating: 10 kAIC
• Pole Configuration: Three-pole
• Dimensions: 3 x 3 x 3 inches
• Weight: 0.99 lb

Material Compliance and Certifications:

• Compliance: This product meets the stringent Federal Specifications Classification W-C375 and is UL 489 certified, ensuring top-quality manufacturing standards and safety compliance.

Suitability:

• Perfect for residential or commercial electrical systems requiring robust overload and short-circuit protection. It is specifically designed to be used with Type BR Loadcenters, ensuring compatibility and performance reliability.

The Eaton BR390 Circuit Breaker is more than just a safeguard; it is a crucial component for enhancing the safety and functionality of your electrical systems. Trust in its superior design and performance to meet your power protection needs.
