BR2100 100A Circuit Breaker

BR2100 100A Circuit Breaker

Elevate the safety and efficiency of your electrical system with the Eaton BR2100 Thermal Magnetic Circuit Breaker. This robust two-pole, plug-on breaker is designed for use with Type BR loadcenters and offers a reliable interruption rating of 10 kAIC at a voltage of 120/240V. Its common trip type and convenient plug-on mounting method ensure a secure and easy installation, making it an ideal choice for both new constructions and system upgrades.

Key Features and Benefits:

• High Amperage Rating: Capable of handling up to 100 amps, providing ample coverage for high-power applications.
• Thermal Magnetic Trip Mechanism: Ensures reliable operation and protection against thermal overload and short circuits.
• Dual Voltage Compatibility: Suitable for systems operating at 120/240V, enhancing versatility across different setups.
• Easy Installation: Designed with a 1-inch plug-on interface for quick and straightforward integration with BR loadcenters.
• Compact Design: With a width of 2 inches and height of 2.4 inches, it fits neatly into your existing electrical panel without requiring additional space.

Technical Specifications:

• Amperage: 100A
• Type: BR 1-Inch plug-on circuit breaker
• Interrupt Rating: 10 kAIC
• Voltage Rating: 120/240 V
• Number of Poles: Two-pole
• Wire Size: #4-1/0 AWG Cu/Al

Material Compliance and Certifications:

• Compliant with Federal Specifications Classification W-C375: ensuring adherence to rigorous safety and quality standards.
• Certified under UL 489: which benchmarks the breaker’s safety performance under extreme conditions.

Suitability:

• Ideal for residential and commercial buildings that require efficient and reliable power distribution and circuit protection. The BR2100 is extensively tested to meet the highest standards of safety and performance, making it a preferred choice among electrical professionals.
