BR1530 - Duplex 15/30 Circuit Breaker

BR1530 - Duplex 15/30 Circuit Breaker

The Eaton BR1530 is a tandem circuit breaker that combines one 15 Amp circuit and one 30 Amp circuit in a single one-inch breaker space. Designed for your compatible Eaton Type BR loadcenters, it provides a way to add or replace circuits when panel space is limited.

You'll often find this breaker in residential panels, apartments, workshops, offices, and light commercial buildings where a mix of 15 Amp and 30 Amp branch circuits is required. Because it occupies a single breaker position while serving two separate circuits, the BR1530 is frequently used when maintaining an existing panel configuration or adding circuits without increasing panel size.

Like many Eaton BR breakers that remain in service for years, the BR1530 is built to last when installed and used within its intended ratings.

Key Features and Benefits

• Tandem breaker with one 15 Amp circuit and one 30 Amp circuit
• Fits a single breaker position in compatible Type BR loadcenters
• Thermal-magnetic trip mechanism
• Plug-on mounting design
• Rated for 120/240VAC applications
• 10kAIC interrupting capacity
• Compatible with #14-4 AWG copper or aluminum conductors
• Used where additional circuits are needed but panel space is limited
• Designed for Eaton Type BR loadcenters


Technical Specifications

• Manufacturer: Eaton

• Catalog Number: BR1530

• UPC: 786676006545

• Product Type: Thermal Magnetic Circuit Breaker

• Series: Type BR

• Amperage Rating: (1) 15A and (1) 30A

• Voltage Rating: 120/240VAC

• Interrupt Rating: 10kAIC

• Number of Poles: Single-Pole Tandem

• Mounting Method: Plug-On

• Wire Size Compatibility: #14-4 AWG Copper/Aluminum

• Dimensions: 3 in. D × 1 in. W × 3 in. H

• Weight: 0.3 lb.


Material Compliance and Certifications

• UL 489 Listed
• Federal Specifications Classification W-C375
• Manufactured to Eaton Type BR circuit breaker specifications
• Intended for installation in compatible Eaton Type BR loadcenters


Where It Works Best

• The BR1530 is commonly used in Eaton Type BR panels installed in homes, apartments, offices, retail spaces, workshops, and light commercial facilities. Typical applications include lighting circuits, receptacle circuits, dedicated appliance circuits, and other branch circuits requiring either 15 Amp or 30 Amp protection. It is also frequently used during panel maintenance and circuit additions where available breaker space is limited.
