BQD6360 - 60Amp Circuit Breaker

BQD6360 - 60Amp Circuit Breaker

The Siemens BQD6360 is a 60-amp, 3-pole, molded-case circuit breaker used in Siemens BQD panelboard systems. Rated for 600/347VAC applications, it is commonly installed in commercial and industrial electrical distribution equipment that operates on three-phase power.

The BQD6360 features a thermal-magnetic trip unit, a 100-amp frame, and a 10kA interrupting rating. It is used in applications where a Siemens BQD breaker with a 60-amp rating and 3-pole configuration is required. The panelboard-mount design and low-tab connection style allow it to be installed in compatible Siemens equipment.

This breaker is often found in your lighting panels, feeder circuits, HVAC equipment, motor loads, and general distribution systems. Schools, hospitals, office buildings, warehouses, manufacturing facilities, and municipal properties are among the many places where BQD series breakers are commonly used.

Key Features and Benefits

• 60-amp current rating
• Three-pole configuration
• Rated for 600/347VAC systems
• Thermal-magnetic trip unit
• 10kA interrupting capacity (10kAIC)
• Panelboard mounting design
• Low-tab connection type
• 100-amp frame size
• Molded case construction
• Suitable for 50/60 Hz applications
• Compatible with Siemens BQD panelboard systems

Technical Specifications

• Manufacturer: Siemens

• Catalog Number: BQD6360

• Product Series: BQD6

• Product Type: Molded Case Circuit Breaker

• Number of Poles: 3

• Current Rating: 60 Amps

• Voltage Rating: 600/347 VAC

• Frequency Rating: 50/60 Hz

• Interrupting Capacity: 10 kAIC

• Frame Size: 100 Amps

• Trip Unit Type: Thermal Magnetic

• Mounting Style: Panelboard Mount

• Connection Type: Low Tab

• Enclosure Material: Molded Case Circuit Breaker

• Maximum Ambient Operating Temperature: 40°C

• Dimensions:
  • Depth: 4 in.
  • Height: 2.9 in.
  • Width: 3 in.
• Net Weight: 1.68 lb

• UPC: 783643304628

• Country of Origin: Mexico


Material Compliance and Certifications

The Siemens BQD6360 meets UL 489 and CSA C22.2 requirements for molded case circuit breakers.

Where It Works Best

• The BQD6360 is commonly used in panelboards serving lighting circuits, feeder circuits, branch circuits, HVAC equipment, motor loads, and general power distribution equipment.
