BQD6350 - 50Amp Circuit Breaker

BQD6350 - 50Amp Circuit Breaker

When you're working with a 347/600VAC distribution system, having the right breaker in place matters. The Siemens BQD6350 is a 3-pole, 50-amp molded case circuit breaker commonly used in commercial and industrial panelboards where three-phase power distribution is part of everyday operations. From lighting systems and feeder circuits to HVAC equipment and general power distribution, this breaker is designed for applications that require a Siemens BQD series breaker with a 50-amp rating.

The BQD6350 features a thermal-magnetic trip unit and a 10kA interrupting capacity, making it suitable for many standard power distribution applications.

You'll often find the BQD6350 in schools, office buildings, healthcare facilities, warehouses, manufacturing plants, and municipal properties operating on 347/600VAC electrical systems. For facilities already using Siemens panelboards, it provides a straightforward way to maintain compatibility while supporting the ongoing needs of the electrical distribution system.

Key Features and Benefits

• 50-amp current rating
• Three-pole circuit breaker configuration
• Rated for 600/347VAC electrical systems
• Thermal-magnetic trip unit for overload and short-circuit protection
• 10kA interrupting capacity (10kAIC)
• Panelboard mounting design
• Low-tab electrical connection type
• 100-amp frame size
• Molded case construction
• Suitable for 50/60 Hz applications
• Designed for use in compatible Siemens BQD panelboard systems
• Helps protect electrical distribution equipment and connected circuits

Technical Specifications

• Manufacturer: Siemens

• Catalog Number: BQD6350

• Product Series: BQD6

• Product Type: Molded Case Circuit Breaker

• Number of Poles: 3

• Current Rating: 50 Amps

• Voltage Rating: 600/347 VAC

• Frequency Rating: 50/60 Hz

• Interrupting Capacity: 10 kAIC

• Frame Size: 100 Amps

• Trip Unit Type: Thermal Magnetic

• Mounting Style: Panelboard Mount

• Connection Type: Low Tab

• Enclosure Material: Molded Case Circuit Breaker

• Maximum Ambient Operating Temperature: 40°C

• Dimensions:
  • Depth: 4 in.
  • Height: 3 in.
  • Width: 3 in.
• Net Weight: 1.649 lb

• UPC: 783643304604

• Country of Origin: Mexico


Material Compliance and Certifications

The Siemens BQD6350 is manufactured in accordance with UL 489 and CSA C22.2 standards for molded case circuit breakers. The breaker is RoHS compliant and meets applicable environmental requirements, including WEEE obligations where required.

Where It Works Best

• The BQD6350 is well suited for commercial and industrial electrical distribution systems operating on 347/600VAC power. Typical applications include panelboards serving lighting circuits, branch circuits, feeder circuits, HVAC equipment, motor loads, and general building power distribution.
