BQD6330 - 30Amp Circuit Breaker

BQD6330 - 30Amp Circuit Breaker

The Siemens BQD6330 is a 3-pole, 30-amp circuit breaker used in 347/600VAC panelboard systems. It's commonly installed in commercial and industrial buildings where three-phase power is used for lighting, branch circuits, and general power distribution. For facilities already using Siemens panelboards, the BQD6330 is often selected for replacement work, system maintenance, and electrical upgrades where matching existing equipment is important.

This breaker features a thermal-magnetic trip unit and a 10kA interrupting rating, making it suitable for many everyday power distribution applications.

With a 30-amp rating and 3-pole configuration, the BQD6330 is well suited for protecting your three-phase circuits in office buildings, schools, healthcare facilities, warehouses, manufacturing plants, and similar properties operating on 347/600VAC electrical systems. Its panelboard-mount design allows it to be installed in compatible Siemens equipment without requiring changes to the existing system layout.

Key Features and Benefits

• 30-amp continuous current rating
• Three-pole circuit breaker configuration
• Rated for 600/347VAC electrical systems
• Thermal-magnetic trip unit
• 10kA interrupting capacity (10kAIC)
• Panelboard mounting design
• Low-tab connection style
• 100-amp frame size
• Molded case construction

Technical Specifications

• Manufacturer: Siemens

• Catalog Number: BQD6330

• Product Series: BQD6

• Product Type: Molded Case Circuit Breaker

• Number of Poles: 3

• Current Rating: 30 Amps

• Voltage Rating: 600/347 VAC

• Frequency Rating: 50/60 Hz

• Interrupting Capacity: 10 kAIC

• Frame Size: 100 Amps

• Trip Unit Type: Thermal Magnetic

• Mounting Type: Panelboard Mount

• Connection Type: Low Tab

• Circuit Breaker Type: BQD

• Enclosure Material: Molded Case

• Maximum Ambient Operating Temperature: 40°C

• Dimensions:
  • Depth: 3 in.
  • Height: 5 in.
  • Width: 3 in.
• UPC: 783643304567

• Country of Origin: Mexico


Material Compliance and Certifications

The Siemens BQD6330 meets UL 489 and CSA C22.2 requirements for molded case circuit breakers.

Where It Works Best

• The BQD6330 is commonly found in panelboards serving lighting systems, branch circuits, feeder circuits, and general distribution equipment.
