BQD335 - 35Amp Circuit Breaker

BQD335 - 35Amp Circuit Breaker

The Siemens BQD335 is a 35-amp, 3-pole circuit breaker designed for use in 480/277VAC three-phase electrical systems. It's commonly found in commercial and industrial panelboards protecting equipment such as HVAC units, lighting circuits, pumps, and motor loads. When current levels exceed safe operating limits, the breaker is designed to trip and disconnect power, helping you prevent damage to wiring and connected equipment.

This model uses a thermal magnetic trip mechanism, providing protection against both overload conditions and short circuits. The panelboard-mount design and low-tab connections make it a practical option for replacement projects, maintenance work, and new installations where a BQD-series breaker is required.

You'll typically see breakers like the BQD335 installed in schools, office buildings, retail centers, warehouses, healthcare facilities, and manufacturing operations.

Key Features and Benefits

• 35 Amp current rating

• 3-pole configuration for three-phase systems

• Rated for 480/277VAC applications

• Thermal magnetic trip unit

• 14 kAIC interrupting capacity

• Panelboard-mount design

• Low-tab electrical connections

• Molded case circuit breaker construction

• Suitable for commercial and industrial electrical distribution systems


Technical Specifications

• Manufacturer: Siemens

• Catalog Number: BQD335

• Series: BQD

• Current Rating: 35 Amps

• Number of Poles: 3

• Voltage Rating: 480/277VAC

• Interrupting Capacity: 14 kAIC

• Frequency: 50/60 Hz

• Trip Unit Type: Thermal Magnetic

• Mounting Style: Panelboard Mount

• Connection Type: Low Tab

• Frame Size: 100A

• Enclosure Type: Molded Case Circuit Breaker

• Dimensions:
  • 3 in. W × 2.8 in. H × 4 in. D
• Maximum Ambient Operating Temperature: 40°C

• Net Weight: 1.601 lb

• Country of Origin: Mexico


Material Compliance and Certifications

• UL 489 Listed

• CSA C22.2 Certified

• RoHS Compliant

• REACH Information Available

• WEEE Compliant


Where It Works Best

• The Siemens BQD335 is commonly used in commercial and industrial panelboards serving lighting systems, HVAC equipment, motor circuits, pumps, and general power distribution. It is well suited for office buildings, schools, hospitals, warehouses, manufacturing facilities, and other properties operating on 480/277VAC electrical systems.
