BQD325 - 25Amp Circuit Breaker

BQD325 - 25Amp Circuit Breaker

The Siemens BQD325 is a 25-amp, 3-pole circuit breaker designed for use in 480/277VAC electrical distribution systems. It helps protect your circuits from overloads and short circuits and is commonly installed in panelboards serving lighting systems, HVAC equipment, pumps, and other three-phase loads. The thermal magnetic trip unit provides protection against both prolonged overcurrent conditions and sudden fault currents, making it a practical choice for your everyday commercial and industrial applications.

Built with a molded case housing and designed for panelboard mounting, the BQD325 is often used in offices, schools, healthcare facilities, warehouses, and manufacturing environments.

Key Features and Benefits

• 25 Amp current rating

• 3-pole configuration for three-phase systems

• Rated for 480/277VAC applications

• Thermal magnetic trip unit

• 14 kAIC interrupting capacity

• Panelboard mount design

• Low-tab electrical connections

• Molded case construction

• Suitable for commercial and industrial electrical systems


Technical Specifications

• Manufacturer: Siemens

• Catalog Number: BQD325

• Series: BQD

• Current Rating: 25 Amps

• Number of Poles: 3

• Voltage Rating: 480/277VAC

• Interrupting Capacity: 14 kAIC

• Frequency: 50/60 Hz

• Trip Unit Type: Thermal Magnetic

• Mounting Style: Panelboard Mount

• Connection Type: Low Tab

• Frame Size: 100A

• Dimensions:
  • 3 in. W × 3 in. H × 4 in. D
• Maximum Ambient Operating Temperature: 40°C

• Net Weight: 1.601 lb

• Country of Origin: Mexico


Material Compliance and Certifications

• UL 489 Listed

• CSA C22.2 Certified

• IEC 60947-2 Compliant

• RoHS Compliant

• WEEE Compliant

• REACH Information Available


Where It Works Best

• The Siemens BQD325 is commonly used in commercial and industrial panelboards protecting lighting circuits, HVAC systems, pumps, motor loads, and general power distribution equipment. It is a good fit for office buildings, schools, hospitals, retail facilities, warehouses, and manufacturing operations that require three-phase circuit protection at 480/277VAC.
