BQD245 - 45Amp Circuit Breaker

BQD245 - 45Amp Circuit Breaker

The Siemens BQD245 is a 45-amp, 2-pole circuit breaker built for 480VAC electrical systems. It’s commonly used in panelboards, branch circuits, and lighting systems to protect wiring and equipment from overloads and short circuits. Its thermal magnetic trip reacts to slow overloads and sudden faults, keeping your circuits safe without interrupting normal operations unnecessarily.

Compact and panelboard-ready, the BQD245 is easy to install, and its low-tab connections make wiring simple. You’ll find it in offices, schools, healthcare facilities, warehouses, retail locations, and industrial plants where consistent 45-amp protection keeps systems running smoothly.

Key Features and Benefits

• 45 Amp continuous rating

• 2-pole configuration for 480VAC circuits

• Thermal magnetic trip for overload and short-circuit protection

• 14 kAIC interrupting capacity

• Panelboard mount for easy installation

• Molded case construction

• Low-tab connections for secure wiring

• Protects circuits, wiring, and connected equipment

• Suitable for commercial and industrial applications


Technical Specifications

• Catalog Number: BQD245

• Manufacturer: Siemens

• Series: BQD

• Poles: 2

• Amp Rating: 45 Amps

• Voltage Rating: 480VAC

• Frequency: 50/60 Hz

• Interrupting Rating: 14 kAIC

• Trip Unit: Thermal Magnetic

• Mounting Style: Panelboard Mount

• Connection Type: Low Tab

• Frame Size: 100A

• Width: 3 in. | Height: 2 in. | Depth: 4 in.

• Enclosure Material: Molded Case

• Max Operating Temp: 40°C

• Net Weight: 1.1 lb


Material Compliance and Certifications

• UL 489 Listed

• CSA C22.2 Certified

• IEC 60947-2 Compliant

• RoHS Compliant

• WEEE Compliant

• REACH Information Available


Where It Works Best

• The BQD245 is commonly used in commercial buildings, schools, healthcare facilities, warehouses, retail locations, and industrial plants.
