BQCH3B100 - 100Amp Circuit Breaker

BQCH3B100 - 100Amp Circuit Breaker

If you're looking for a BQCH3B100, you're likely replacing an existing breaker or matching the requirements of equipment already in service. This 100 amp, 3-pole bolt-on molded case circuit breaker is built on the BQCH frame and features a 14kA interrupting rating at 480VAC. When replacing a breaker, matching the frame type, amperage, pole configuration, and mounting style is often the easiest way to ensure compatibility with the original installation.

The BQCH3B100 is also HACR rated, making it suitable for heating, air conditioning, and refrigeration equipment where that designation is required. With a 40°C ambient temperature rating, it can be used in a variety of operating conditions.

Key Features and Benefits

• 100 amp current rating
• 3-pole configuration for three-phase electrical systems
• Bolt-on mounting design
• BQCH frame type
• Molded case circuit breaker construction
• 14kA interrupting rating at 480VAC
• HACR rated
• Rated for operation in 40°C ambient conditions
• Intended for replacement applications requiring matching specifications
• Compatible with equipment designed for BQCH frame breakers
• Built to last


Technical Specifications

• Part Number: BQCH3B100

• Frame Type: BQCH

• Circuit Breaker Type: Molded Case Circuit Breaker

• Poles: 3

• Amperage Rating: 100 Amps

• Interrupting Rating: 14kA @ 480VAC

• Mounting Type: Bolt-On

• Ambient Temperature Rating: 40°C

• HACR Rated: Yes

• Dimensions:
  • Width: 3.00 in.
  • Height: 4.49 in.
  • Depth: 2.70 in.
• Dimensions: 3.00"W x 4.49"H x 2.70"D

• Approximate Shipping Weight: 4.0 lbs.


Material Compliance and Certifications

• HACR Rated
• Rated for operation in 40°C ambient conditions
• Molded case circuit breaker construction
• Suitable for use in compatible equipment operating within the breaker's published ratings


Where It Works Best

• The BQCH3B100 is commonly used in commercial buildings, warehouses, manufacturing plants, schools, healthcare facilities, and similar locations that utilize three-phase power.
