BQCH3B070 - 70Amp Circuit Breaker

BQCH3B070 - 70Amp Circuit Breaker

When keeping electrical systems running smoothly, finding the correct replacement breaker is all about matching the original specifications. The BQCH3B070 is a 70 amp, 3-pole bolt-on molded case circuit breaker designed for applications that require a BQCH frame breaker with a 14kA interrupting capacity at 480VAC. Whether you're performing routine maintenance, replacing a failed breaker, or servicing existing distribution equipment, this breaker provides the form, fit, and function needed for compatible installations.

Its bolt-on mounting design creates a secure connection within approved electrical equipment, while the 3-pole configuration makes it well-suited for three-phase power systems commonly found in commercial and industrial environments. The HACR rating also makes it a suitable choice for heating, ventilation, air conditioning, and refrigeration applications where that designation is required. Built to last and engineered for dependable circuit protection, the BQCH3B070 helps protect electrical systems from overloads and short circuits while maintaining compatibility with equipment designed around the BQCH platform.

Key Features and Benefits

• 70 amp current rating for a variety of commercial and industrial applications
• 3-pole design for three-phase electrical systems
• Bolt-on mounting for secure installation in compatible equipment
• BQCH frame type for proper fit and replacement applications
• Molded case construction designed for long-term service
• 14kA interrupting capacity at 480VAC
• HACR rated for qualifying HVAC and refrigeration equipment
• Rated for operation in ambient temperatures up to 40°C
• Ideal for maintenance, repair, and replacement projects
• Built to last in demanding electrical environments


Technical Specifications

• Part Number: BQCH3B070

• Frame Type: BQCH

• Breaker Type: Molded Case Circuit Breaker

• Amperage: 70 Amps

• Poles: 3

• Voltage Rating: 480VAC

• Interrupting Capacity: 14kA @ 480VAC

• Mounting Style: Bolt-On

• Ambient Rating: 40°C

• HACR Rated: Yes

• Dimensions:
  • Width: 3.00 in.
  • Height: 4.49 in.
  • Depth: 2.70 in.
• Dimensions: 3.00"W x 4.49"H x 2.70"D

• Approximate Shipping Weight: 4.0 lbs.


Material Compliance and Certifications

• HACR Rated
• Molded case circuit breaker construction
• Rated for operation in 40°C ambient conditions
• Designed for use in compatible electrical distribution systems and equipment meeting the breaker's published ratings


Where It Works Best

• The BQCH3B070 is commonly found in commercial buildings, industrial facilities, schools, healthcare facilities, manufacturing operations, and other locations that rely on three-phase electrical distribution. Typical applications include HVAC equipment, refrigeration systems, motor loads, branch circuit protection, control panels, and power distribution equipment requiring a 70 amp 3-pole bolt-on circuit breaker.
