BQCH3B060 - 60Amp Circuit Breaker

BQCH3B060 - 60Amp Circuit Breaker

If you're looking for a BQCH3B060, you're likely replacing an existing breaker or matching the requirements of equipment already in service. This 60 amp, 3-pole bolt-on molded case circuit breaker is designed for installations that require a BQCH frame and a 14kA interrupting rating at 480VAC. When those specifications match the breaker already installed, replacement is typically much more straightforward.

The BQCH3B060 is also HACR rated, making it suitable for heating, air conditioning, and refrigeration equipment where that rating is required. Rated for operation in ambient temperatures up to 40°C, it can be used in a variety of commercial and industrial settings. Whether you're replacing a breaker during scheduled maintenance or identifying the correct part for an existing system, this model is built to last and designed for equipment that requires these exact ratings, dimensions, and mounting characteristics.

Key Features and Benefits

• 60 amp current rating
• 3-pole configuration for three-phase power systems
• Bolt-on mounting design
• BQCH frame type
• Molded case circuit breaker construction
• 14kA interrupting capacity at 480VAC
• HACR rated
• Rated for operation in 40°C ambient conditions
• Designed for replacement applications requiring matching specifications
• Compatible with equipment designed for BQCH frame breakers
• Built to last


Technical Specifications

• Part Number: BQCH3B060

• Frame Type: BQCH

• Circuit Breaker Type: Molded Case Circuit Breaker

• Amperage Rating: 60 Amps

• Number of Poles: 3

• Voltage Rating: 480VAC

• Interrupting Rating: 14kA @ 480VAC

• Mounting Type: Bolt-On

• Ambient Temperature Rating: 40°C

• HACR Rated: Yes

• Dimensions:
  • Width: 3.00 in.
  • Height: 4.49 in.
  • Depth: 2.70 in.
• Dimensions: 3.00"W x 4.49"H x 2.70"D

• Approximate Shipping Weight: 4.0 lbs.


Material Compliance and Certifications

• HACR Rated
• Molded case circuit breaker construction
• Rated for operation in 40°C ambient conditions
• Suitable for use in compatible equipment meeting the breaker's published electrical ratings


Where It Works Best

• The BQCH3B060 is commonly used in commercial buildings, warehouses, manufacturing plants, schools, healthcare facilities, and similar environments utilizing three-phase electrical systems.
