BQCH3B040 - 40Amp Circuit Breaker

BQCH3B040 - 40Amp Circuit Breaker

If you're searching for a BQCH3B040, you're probably looking to replace an existing breaker or match the specifications of equipment already in service. This 40 amp, 3-pole bolt-on molded case circuit breaker is designed for applications that require a BQCH frame and a 14kA interrupting rating at 480VAC. When the frame type, amperage, and mounting style match what's already installed, finding the right replacement becomes much simpler.

This breaker is also HACR rated, making it suitable for heating, air conditioning, and refrigeration applications where that rating is required. With a 40°C ambient rating, it can be used in a variety of operating environments. Whether you're replacing a failed breaker, completing routine maintenance, or tracking down the correct part for an existing installation, the BQCH3B040 is built to last and designed for equipment that calls for these exact specifications.

Key Features and Benefits

• 40 amp current rating
• 3-pole configuration for three-phase applications
• Bolt-on mounting design
• BQCH frame type
• Molded case circuit breaker construction
• 14kA interrupting rating at 480VAC
• HACR rated
• Rated for operation in 40°C ambient conditions
• Compatible with equipment designed for BQCH frame breakers
• Suitable for maintenance and replacement applications
• Built to last


Technical Specifications

• Part Number: BQCH3B040

• Frame Type: BQCH

• Circuit Breaker Type: Molded Case Circuit Breaker

• Poles: 3

• Amperage Rating: 40 Amps

• Voltage Rating: 480VAC

• Interrupting Rating: 14kA @ 480VAC

• Mounting Type: Bolt-On

• Ambient Temperature Rating: 40°C

• HACR Rated: Yes

• Dimensions:
  • Width: 3.00 in.
  • Height: 4.49 in.
  • Depth: 2.70 in.
• Dimensions: 3.00"W x 4.49"H x 2.70"D

• Approximate Shipping Weight: 4.0 lbs.


Material Compliance and Certifications

• HACR Rated
• Molded Case Circuit Breaker construction
• Rated for operation in 40°C ambient conditions


Where It Works Best

• The BQCH3B040 is commonly used in commercial buildings, warehouses, manufacturing facilities, schools, healthcare facilities, and other locations utilizing three-phase electrical systems. Typical applications include HVAC systems, refrigeration equipment, motor circuits, branch circuit protection, control panels, and electrical distribution equipment requiring a 40 amp, 3-pole bolt-on circuit breaker with a 14kA interrupting rating at 480VAC.
